OPERATING CONTROLS
With the exception of the AC mains switch, which is located on the rear panel of the power supply unit, all operating
controls are located on the front panel of the preamp.
AC mains switch The AC mains switch (33) which completely disconnects the AC power to the unit is
located on the rear panel of the 077 or on the rear panel of the external power supply unit
above the AC mains terminal. By switching to the ON position the standby transformer is
powered up.
POWER switch The POWER switch (8) switches the preamp on and off, presuming the AC mains switch is
in the ON position.
With the POWER switch (8) set to “OFF“ all functions of the preamp are powered down.
Flipping the POWER switch (8) from “OFF“ to “STBY“, the POWER LED (7) lights up
orange. This shows that the unit is in standby mode.
When the POWER switch is in “STBY“ position the unit can be switched on and off by
pulling up the POWER switch, pushing the POWER button on the BURMESTER remote
control, the Burlink interface or by the DC IN jack.
In operating mode (ON) the POWER LED (7) lights up red and all functions of the preamp
are activated.
PLEASE NOTICE: Always switch off the preamp with the POWER switch first before
bringing the AC mains switch into OFF position.
Volume selector The Volume selector (6) controls the volume level in 61 steps from 00 (mute) to 60
(maximum volume) or in dB-step from MUTE to +5dB (maximum volume with LOW
amplification) or + 21dB (maximum volume with HIGH amplification). The volume setting
can be selected separately for MAIN and RECORD level. To change between MAIN and
RECORD level pull the RECORD/PHONES switch key (14) up at the or push the MODE
button on your remote control. If the REC/MAIN LED (5) lights up, you are controlling the
RECORD level.
The selected volume level will be shown in the alphanumeric display (4).
The volume selector also controls functions in the SETUP menus.
Input selector With the input selector (1) you select the input you want to listen to. The input selection
can be done separately for MAIN and RECORD level. To change between MAIN and
RECORD level push the RECORD/PHONES switch key (14) up or push the MODE button
on your remote control. If the REC/MAIN LED (5) lights up, you are controlling the
RECORD level, if it doesn’t light up you are controlling the MAIN level.
The selected input will be shown in the alphanumeric display (4).
The input selector also controls functions in the SETUP menus.
