Monitor lock Through factory settings the OUTPUT REC (22) of the preamp 077 is preset to be
connected to an analogue tape recorder. The INPUT 3 = TAPE cannot be chosen for
recording, because of the audio feedback that would result of this connection.
If your analogue recording device is connected to another input, it is possible to activate the
monitor lock for this input and lift the locking for INPUT 3.
Adjustment options are available in the RECORD SETUP in submenu LOCK.
For specific instructions please refer to THE SETUP MENU/ RECORD SETUP.
This option cannot be chosen if the volume control for the RECORD level is variable.
Volume balance Some spatial arrangements require shifting the volume conditions for each reproducing
channel. The volume shift is realized by reducing one of the two stereo channels. It is
possible to reduce one channel of the preamp 077 up to 9 dB (factor 2.8) in steps of 1 dB,
and for specific situations to switch off completely.
Adjustment options are available in the MAIN SETUP in submenu M-BAL. For the
RECORD level adjustment options are available in the RECORD SETUP in submenu R-
BAL. If the volume is fixed for the RECORD level, the balance setting has no effect.
For specific instructions please refer to THE SETUP MENU/ MAIN SETUP and RECORD
SETUP respectively.
Input names Through factory settings all inputs of the preamp 077 are assigned with specific names. You
may, however label the inputs 1 through 6 with other names. We provide a range of names.
It is of course possible to choose an individual name, e.g. the type of your device.
Adjustment options are available in the GLOBAL SETUP in submenu INPUT NAMES.
For specific instructions please refer to THE SETUP MENU/ GLOBAL SETUP.
Factory setting assigns the following names:
• INPUT 1 CD
• INPUT 2 TUNER
• INPUT 3 TAPE
• INPUT 4 AUX1
• INPUT 5 AUX2
• INPUT 6 AUX3
• MODULE INPUT LINE (if equipped with LINE MODULE)
PH-MC (if equipped with PHONO MC MODULE)
PH-MM (if equipped with PHONO MM MODULE)
DA USB (if equipped with D/A-CONVERTER MODULE)
DA RCA (if equipped with D/A CONVERTER MODULE)
Restoring factory settings will reset all the input names to the ones above.
4 Channel Mode This option allows you to use both, the MAIN and RECORD level, as one preamp. When
activated only the MAIN level is operable. The RECORD level will automatically reproduce
the selected input of the MAIN level. Also the volume will be adjusted for both levels.
However you have the option to fade the volume of the RECORD level in reverence to the
MAIN level.
For the 4 Channel Mode the activation option is available in the GLOBAL SETUP in
submenu 4CH-MODE.
For specific instructions please refer to THE SETUP MENUS / GLOBAL SETUP.
For the FADER option please refer to THE SETUP MENUS / MAIN SETUP
