Burmester 077 User Manual

38
TECHNICAL SPECIFICATIONS
Dimensions Preamp incl. base plate (W x H x D) 450 x 160 x 340 mm
(17.7 x 6.3 x 13.4 inches)
Power supply unit incl. base plate (B x H x T) 450 x 160 x 340 mm
(17.7 x 6.3 x 13.4 inches)
Weight Preamp incl. base plate approx. 25 kg
(55.0 lbs)
Power supply unit incl. base plate approx. 25 kg
(55.0 lbs)
Mains voltage and fuses 230V 50Hz/60Hz ex. power supply 2 x slow 1A E, 1 x slow 50mA E
115V 50Hz/60Hz ex. power supply 2 x slow 2A E, 1 x slow 100mA E
230V 50Hz/60Hz 1 x slow 500mA E, 1x slow 50mA E
200V 50Hz/60Hz 1 x slow 500mA E, 1x slow 50mA E
115V 50Hz/60Hz 1 x slow 1A E, 2x slow 100mA E
Power consumption ON 55 W
STBY 4 W
OFF 4 W
PLEASE NOTE: The dimensions do not include the length of binding posts and the space needed for
plugs of interconnect cables.
The technical data and design of this product are subject to change without notice.
