THE SETUP MENUS
The SETUP menus of the preamp 077 allow comfortable programming of certain basic settings as well as special
functions. Changes in some of the settings have an impact on the reproduction of the signal. We recommend,
selecting a moderate volume level before activating a setup.
NOTICE: While the SETUP menu is active, the volume selector (6) on the front panel of the 077 serves to change
the settings of the various menu items. During this procedure the volume level can only be changed by the volume
buttons on your remote control.
Activating the SETUP Menus
GLOBAL SETUP: Pushing down the switch key (15) or longer pressing (approx. 2 seconds) the MENU
button on your remote control activates the GLOBAL SETUP.
MAIN SETUP: Pulling up the switch key (15) or shortly pressing the MENU button on your remote
control activates the MAIN SETUP, when the unit is in MAIN level.
RECORD SETUP: Pulling up the switch key (15) or shortly pressing the MENU button on your remote
control activates the RECORD SETUP, when the unit is in RECORD level.
PHONES SETUP: Pushing down the switch key (14) or longer pressing (approx. 2 seconds) the MODE
button on your remote control activates the PHONES SETUP.
PHONO SETUP: Pulling up the switch key (12) or shortly pressing the AUDIO button on your remote
control activates the PHONO SETUP.
This menu can only be activated, if a PHONO MC or PHONO MM module is equipped
and the PH-MC or PH-MM input is selected.
AS EQUIPPED:
MC SETUP: Pushing down the switch key (12) or longer pressing (approx. 2 seconds) the AUDIO
button on your remote control activates the MC SETUP.
This menu can only be activated, if a PHONO MC module is implemented and the PH-
MC input is selected.
MM SETUP: Pushing down the switch key (12) or longer pressing (approx. 2 seconds) the AUDIO
button on your remote control activates the MM SETUP.
This menu can only be activated, if a PHONO MM module is implemented and the PH-
MM input is selected.
Select menu item The different items of the setup menus are selected by turning the input selector (1) on the
front panel or pressing the navigation buttons
on your remote control. (check tables on
page 21)
The alphanumeric display (4) shows the selected item.
Change settings To change the setting of a selected menu item turn the volume selector (6) on the front
panel or press the navigation buttons
on your remote control.
The selected value of the menu item is indicated on the right side of the alphanumeric
display (4).
The selected value of any menu item will be saved immediately.
Exit SETUP Exiting the setup menu is done by pushing the same switch key that has activated the setup
or by shortly pushing the MENU button on your remote control. The display will show
SETUP SAVED!.
