THE MC SETUP
The MC SETUP offers the adjustment of functions like AMPLIFICATION and INPUT RESISTANCE.
NOTICE: This menu is only available if your preamp 077 is equipped with a PHONO MC module and the input PH-
MC is selected
The following chart provides an overview of all menu items, which may be adjusted in the MC SETUP. The factory
settings (defaults) are listed in brackets. Subsequent to the chart you will find a detailed description of the menu
items.
MENU ITEM DESCRIPTION DISPLAY VALUE
Amplification Adjusts PHONO MC amplification GAIN
54dB / 60dB /
(66dB) / 72dB
Input resistance Adjusts input capacitance of PHONO MC module LOAD
33
/ 47
/ 91
/
(120
) / 390
/
47k
The MC SETUP MENU is activated by pushing down the switch key (12) on the front panel or by longer pressing the
AUDIO button (approx. 2 sec) on your remote control. The display indicates the activation by showing MC SETUP,
followed by the first menu item.
To exit and automatically save the menu push down the switch key (12) or press the AUDIO button on your remote
control.
Amplification With this option you are able to adjust the playback volume of the PHONO MC module to
your record player.
With the left rotary switch or the navigation buttons
on your remote control select the
option GAIN.
With the right rotary switch or the navigation buttons
on your remote control select the
amplification.
Input resistance With this option you are able to adjust the input resistance of the PHONO MC module to the
pickup of your record player. Usually the manufacturers of pickup systems have
recommended settings for this option. Of course you can try different settings, whatever
sounds best to your ears.
With the left rotary switch or the navigations buttons
on your remote control select the
option LOAD.
With the right rotary switch or the navigations buttons
on your remote control select
the desired input resistance.
