ATOMO
AT01 • AT02
AT04
p.
21 - Manual Code:
119GV18ver.
1.1 12/2011 © CAME Cancelli Automatici S.p.a. - The data and information in this manual may be changed at any time and without obligation on the part of Came Cancelli Automatici S.p.a. to notify said changes.
ENGLISH
AF card
Connect RG58 antenna cable to the apposite terminals.
Cut off main power and/or disconnet batteries and insert the radiofrequency card.
N.B.: The elctronic card accepts the radiofrequency card only when powered.
see instruction sheet inside 001 AF43SR radiogre-
quency card package box
Frequency
MHz
Radiofrequency
card
Series of
transmitters
FM 26.995 AF130 TFM
FM 30.900 AF150 TFM
AM 26.995 AF26 TOP
AM 30.900 AF30 TOP
AM 40.685 AF40 TOUCH
AF43S / AF43SM TAM / TOP
AF43SR ATOMO
AF43S / AF43TW TWIN
AM 868.35 AF868 TOP
Antenna
Radiofrequency card
Transmitters
Activating the radio command
