Canon imagePRESS C800 Series Operator's Maintenance Manual

2
2
2-2
2-2
Procedure of Replacement/Cleaning > List of Operator Replaceable/Cleanable Parts > Cleanable Parts
Procedure of Replacement/Cleaning > List of Operator Replaceable/Cleanable Parts > Cleanable Parts
List of Operator Replaceable/Cleanable Parts
The parts that need to be replaced/cleaned after a certain period of use, their estimated life (number of sheets) and the cleaning interval (number of seconds) are shown in the following table. Be sure
to replace or clean the part in order to maintain the performance and functions of the host machine.
NOTE:
• The expected life is based on the median of the evaluation data. The actual life may be differed depending on the installation environment and/or the machine use. Please note that parts numbers are
subject to change due to improvement or others.
• The number written in “Adjustment after replacement” indicates the adjustment order.
Replaceable Parts
As of November 2014
Category Part name Part No.
Replacement interval (sheets)
Q'ty
Adjustment after replacement
Parts replaced
by operator
Reference
PRESS
C800
PRESS
C700
PRESS
C600
PRESS
C60
Auto Adjust
Gradation
Correct
Shading
Auto Correct
Color Tone
Settings
Output Test
Page
Transfer
area
Secondary Transfer Outer Roller FC0-9786 900,000 750,000 600,000 600,000 1 1 2 3 4
Secondary
Transfer Unit
p. 2-3
Fixing area
Fixing Assembly / Fixing Belt Unit FM1-C721 600,000 500,000 400,000 400,000 1
1 2 3 4
Fixing
Assembly
p. 2-7
Fixing Assembly / Pressure Belt Unit FM1-C722 600,000 500,000 400,000 400,000 1
Fixing Assembly / Pressure Sub
Thermistor (Rear)
FK2-7870 1,200,000 1,000,000 600,000 600,000 1
Fixing Assembly / Pressure Sub
Thermistor (Front)
FK2-7871 1,200,000 1,000,000 600,000 600,000 1
Cleanable Parts
As of November 2014
Category Part name
Part
No.
Cleaning interval (seconds)
Q'ty
Adjustment after replacement
Parts replaced
by operator
Remarks Reference
PRESS
C800
PRESS
C700
PRESS
C600
PRESS
C60
Auto Adjust
Gradation
Correct
Shading
Auto
Correct
Color Tone
Settings
Output Test
Page
Cleaning
Fixing Refresh
Roller
- 3,600 3,600 3,600 3,600 1 1 2 3 4
Fixing Refresh
Roller
The counter value in service mode indicates
the time (the number of seconds) during
which the Refresh Roller is engaged.
Equivalent to 600,000 under normal
conditions
p. 2-13
T-2-1
T-2-2
