Canon imagePRESS C800 Series Operator's Maintenance Manual

2
2
2-3
2-3
Procedure of Replacement/Cleaning > Transfer area > Replacing the Secondary Transfer Unit > Replacement procedure
Procedure of Replacement/Cleaning > Transfer area > Replacing the Secondary Transfer Unit > Replacement procedure
Transfer area
Replacing the Secondary Transfer Unit
■
Replacement procedure
CAUTION:
Be sure not to touch the surface [A] of the Secondary Transfer Outer Roller when
replacing
[A]
F-2-2
F-2-1
1) Open the Front Cover.
2) Turn over the lever [1] and pull out the Fixing Feed Unit [2].
[1]
[2]
F-2-3
