Canon imagePROGRAF iPF765 User Manual

• K Sharpen Text
Activate this option to print text more sharply.
•
T Economy Printing
Select this checkbox to reduce the amount of ink consumed during printing. However, the print quality is worse
than for normal printing.
Select this mode if you want to conserve ink when checking drawings, for example. Depending on the A Media
Type and F Print Quality settings, this mode may not be available.
Paper Information on Printer Dialog Box
Paper Information on Printer Dialog Box
On the Paper Information on Printer dialog box, you can obtain information on the paper in the printer and configure
printer driver settings for the paper source and media type.
Note
• To display the Paper Information on Printer dialog box, on the Main sheet, click Get Information by Media Type.(See
"Main Sheet →P.186 ")
•
A Paper Source
Shows the paper source supported by the printer, as well as information about the loaded paper. To update the
paper source and media type settings in the printer driver, select the desired Paper Source option and click OK.
Paper Detailed Settings Dialog Box
Paper Detailed Settings Dialog Box
The Paper Detailed Settings dialog box offers the following settings. For details on settings items, refer to the printer
driver help.
iPF765
Paper Information on Printer Dialog Box
User's Guide
Windows Software Printer Driver
189

Canon imagePROGRAF iPF765 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Storage media	HDD
Internal storage capacity	250 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
