Canon imagePROGRAF iPF765 User Manual

If multiple errors occur, tabs related to errors other than the error currently shown flash. Press the ◀ or ▶ button
to access other tabs and check those errors. If multiple errors occur that are related to the Job tab and Settings/
Adj. tab, each error message is displayed for 4 seconds on each tab before another message is shown.
How to View Instructions With Navigate
How to View Instructions With Navigate
You can refer to instructions for loading paper, replacing ink tanks, and performing other operations on the printer con-
trol panel.
1 Press the Navigate button.
2 Press ▲ or ▼ to select the desired navigation menu.
3 Press ▲ or ▼ to select View Op. Guide, and then press the OK button.
Instructions are now displayed.
iPF765
How to View Instructions With Navigate
User's Guide
Control Panel Operations and Display Screen
483

Canon imagePROGRAF iPF765 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Storage media	HDD
Internal storage capacity	250 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
