Canon imagePROGRAF iPF765 User Manual

Dialog Area
Dialog Area
You can select the layout and print on the center.
•
Media Type / Paper Source /Paper Size
You can confirm the information that is set.
• Layout Selection
You can print which conserves paper by selecting the layout.
For more information about Layout Selection, see "Printing with Selecting the Layout." →P.215
•
Center Originals Across Roll
You can print on the center of the media loaded in the printer.
For more information about Center Originals Across Roll, see "Print on the Center." →P.217
Note
• Available only if rolls are selected in Paper Source.
•
No Spaces at Top or Bottom
You can save paper on not to feed roll paper for the empty spaces when the print data contains spaces at the top
or bottom.
For more information about No Spaces at Top or Bottom, see "Not Print Spaces at the Top/Bottom." →P.218
Note
• Available only if rolls are selected in Paper Source.
•
Print Button
Click the button to start printing.
Dialog Area
iPF765
User's Guide
Windows Software Preview
212

Canon imagePROGRAF iPF765 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Storage media	HDD
Internal storage capacity	250 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
