Canon imagePROGRAF iPF765 User Manual

• Enhancing printing quality
Setting Item Description
Unidirectional Printing Choosing unidirectional printing can improve printing results if lines are printed crooked or images
are uneven. However, this takes more time than regular printing.
Thicken Fine Lines Choose this option to make fine lines clearer in CAD drawings or similar documents.
Sharpen Text Choose this option to print intricate text more distinctly.
Reduce Print Unevenness (*1) Choose this option to counteract uneven printing.
Economy Printing When this mode is selected, less ink is consumed than in regular printing, but the quality is dimin-
ished.
Select this mode if you want to conserve ink when checking drawings, for example. Depending on
the Media Type and Print Quality settings, this mode may not be available.
*1: Displayed in Mac OS X.
Note
• To print at a higher level of quality, in the printer driver, choose High or Highest in Print Quality, and choose Unidirec-
tional Printing as the direction of printing.
For instructions on specifying the print quality and color settings before printing, refer to the following topics, as
appropriate for your computer and operating system.
• Choosing the Document Type and Printing Conditions (Windows) →P.65
• Choosing the Document Type and Printing Conditions (Mac OS X) →P.67
Choosing the Document Type and Printing Conditions (Windows)
Choosing the Document Type and Printing Conditions (Windows)
You can specify your own print settings instead of using the Print Target presets. As an example, this topic describes
how to print CAD drawings as clearly as possible, with sharp lines and text.
1 Choose Print in the application menu.
2 Select the printer in the dialog box, and then display the printer driver dialog box.(See "Accessing the Printer
Driver Dialog Box from Applications(Windows) →P.183 ")
3
Make sure the Main sheet is displayed.
4 In the A Media Type list, select the type of paper that is loaded.
iPF765 Choosing the Document Type and Printing Conditions (Windows)
User's Guide
Enhanced Printing Options Adjusting Images
65

Canon imagePROGRAF iPF765 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Storage media	HDD
Internal storage capacity	250 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
