Canon imagePROGRAF iPF765 User Manual

2
In the Media Type list, select the name of the media to
switch off or on for display.
Click the Show/Hide button.
The selected paper is alternately shown or hidden.
Note
• The names of media switched for non-display appear grayed out in the Media Type list.
• Each time you click the Show/Hide button, the display mode cycles from showing both the printer driver and printer
panel, to hiding both the printer driver and printer panel, and then to showing only the printer panel.
3
In the Edit Media Types dialog box, click the Update
button.
The Update Media Types wizard is started at this
point. For details on the procedure to update paper in-
formation using the Update Media Types wizard, see
"Updating Media Types." →P.434
Important
• Be sure to click the Update button. If you do not, your changes will not be applied to the printer and printer driver.
Switching Media Types Display Show/Hide iPF765
User's Guide
Mac OS X Software Media Configuration Tool
432

Canon imagePROGRAF iPF765 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Storage media	HDD
Internal storage capacity	250 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
