Projecting 34
You can use the HDMI input jack, PC input jack, or the Mini-B USB jack to connect
the projector to a computer.
If the selected input is not projected even when the projector is on (P27), check that the
computer is on and that the steps have been followed correctly. Also check the cable
connections.
Connecting using the PC input jack
You can project analog PC images by connecting a computer cable to the projector's
PC input jack.
• Use the computer cable supplied (P18).
1. Connect the computer cable supplied to the computer's monitor output jack.
2. Connect the other end of the computer cable to the projector's PC input jack.
3. To use the projector's internal speaker, connect a commercially available audio
cable to the computer's audio output jack, and the other end to the projector's
audio input jack.
4. Set the projector's input signal to PC (P28).
Connecting to a computer
Jack name Jack shape Notes
HDMI input jack Transmits high resolution digital
images and audio with a single cable
PC input jack Transmits high resolution analog
signals
Mini-B USB jack PC screen display
Transmits files from the PC to the
internal memory of the projector
Notebook or desktop computer
Computer cable (supplied)
Audio cable
(commercially
available)
To Next Page
