Canon MR-14EX II User Manual

15
Attaching the Control Unit to the Camera
1
Attach the control unit.
 Slip the control unit’s mounting foot
all the way into the camera’s hot
shoe.
2
Secure the control unit.
 Slide the mounting foot lock lever to
the right.
 When the lock lever clicks in place, it
is locked.
3
Detach the control unit.
 While pressing the lock-release
button, slide the lock lever to the left
and detach the control unit.
Attaching the Control Unit to the Camera
 Be aware that the batteries may become hot, if you change batteries after
firing flashes continuously.
 Batteries are required by the flash unit even when an external power
source (p.68) is used.
 When <!> is displayed, or the LCD panel display turns off during
recycling, replace the batteries with new ones.
 Use a new set of four batteries of the same brand. When replacing the
batteries, replace all four at one time.
 AA/HR6 Ni-MH batteries can also be used.
Be sure to turn off the MR-14EX II before attaching or detaching it.

Canon MR-14EX II Specifications

General

Type	Macro Ring Lite
Guide Number	14 (ISO 100, meters)
Power Source	4 x AA batteries
Color Temperature	Approx. 5500 K
Compatibility	Canon EOS cameras
Flash Modes	Manual
Recycling Time	Approx. 0.1 - 5.5 seconds
Weight	Approx. 455 g (without batteries)
