Canon MR-14EX II User Manual

71
If a problem occurs with the flash, first refer to this Troubleshooting
Guide. If this Troubleshooting Guide does not resolve the problem,
contact your dealer or nearest Canon Service Center.
 Normal Shooting
 Make sure that the batteries are installed in the correct orientation (p.14).
 Make sure that the battery compartment cover is closed (p.14).
 Replace the batteries with new ones.
 Insert batteries into the flash unit, even when using an external power
source (p.68).
 Insert the mounting foot into the camera’s hot shoe all the way, slide the
lock lever to the right, and secure the control unit to the camera (p.15).
 If the <G> indication remains displayed for 30 sec. or longer,
replace the batteries (p.14).
 If the electrical contacts of the control unit or camera are dirty, wipe the
contacts (p.9) using a dry cloth.
 The MR-14EX II’s auto power off has activated. Press the shutter button
halfway, or press the test flash button (p.18).
 If there is a highly reflective object in the picture, use FE lock (p.29).
 If the main subject looks very dark or very bright, set flash exposure
compensation (p.27).
 With high-speed sync, the faster the shutter speed, the lower the guide
number will be. Move closer to the subject (p.30).
 Do not fire receiver C directly pointing toward the main subject (p.44).
Troubleshooting Guide
The power does not turn on.
The MR-14EX II does not fire.
The power turns off by itself.
Pictures are underexposed or overexposed.

Canon MR-14EX II Specifications

General

Type	Macro Ring Lite
Guide Number	14 (ISO 100, meters)
Power Source	4 x AA batteries
Color Temperature	Approx. 5500 K
Compatibility	Canon EOS cameras
Flash Modes	Manual
Recycling Time	Approx. 0.1 - 5.5 seconds
Weight	Approx. 455 g (without batteries)
