Canon MR-14EX II User Manual

18
1
Set the power switch to <K>.
 The flash recycling starts.
 During recycling, <G> is
displayed on the LCD panel. When
flash recycling is completed, this
indicator disappears.
2
Check that the flash is ready.
 The state of the flash-ready lamp
changes from off to green (Quick
flash ready) to red (fully charged).
 Press the test flash button (flash-
ready lamp) to fire a test flash.
The Quick flash function enables flash shooting when the flash-ready
lamp is lit green (before the flash is fully charged). It is available when
the camera’s drive mode is set to single shooting. The flash output will
be approx. 1/2 to 1/5 of the full output, but it is effective for shooting with
a shorter firing interval.
Note that you cannot use Quick flash when continuous shooting, FEB,
manual flash, or wireless multiple flash shooting is set.
To save battery power, the power will turn off automatically after approx.
90 sec. of idle use. To turn on the MR-14EX II again, press the camera’s
shutter button halfway, or press the test flash button (flash-ready lamp).
Turning on the Power
Quick Flash
Auto Power Off
 Quick flash cannot be used when the flash mode is set to <b>.
 A test flash cannot be fired when the camera’s 3/1/4/7/2
timer is active.

Canon MR-14EX II Specifications

General

Type	Macro Ring Lite
Guide Number	14 (ISO 100, meters)
Power Source	4 x AA batteries
Color Temperature	Approx. 5500 K
Compatibility	Canon EOS cameras
Flash Modes	Manual
Recycling Time	Approx. 0.1 - 5.5 seconds
Weight	Approx. 455 g (without batteries)
