Canon MR-14EX II User Manual

16
Attach the flash unit to the front of the macro lens.
Attach the flash unit to the front
of the lens while holding down
the release button.
 Make sure that the flash unit is
securely attached.
 When rotating the flash unit, lightly
press the release button while
rotating it.
 Detach the flash unit while holding
down the release button.
Attach the provided lens cap to the flash unit when it is not used in order
to protect the lens.
 A 67 mm diameter filter can also be
attached to the flash unit (p.17).
Attaching the Flash Unit to the Lens
Attaching the Lens Cap
 Be sure to attach the flash unit to the lens when shooting. Shooting while
holding the flash unit in your hand may result in a low temperature burn.
 Do not touch the flash unit or batteries immediately after continuous flash
firing or modeling flash (p.23). Touching them may result in a burn. Make
sure that the flash unit has cooled before detaching the flash unit or
replacing batteries.
When using the following lenses, attach the Macrolite Adapter (sold
separately) to the front of the lens (filter thread) and then attach the flash
unit.
• EF100mm f/2.8L Macro IS USM: Macrolite Adapter 67
• EF180mm f/3.5L Macro USM: Macrolite Adapter 72C

Canon MR-14EX II Specifications

General

Type	Macro Ring Lite
Guide Number	14 (ISO 100, meters)
Power Source	4 x AA batteries
Color Temperature	Approx. 5500 K
Compatibility	Canon EOS cameras
Flash Modes	Manual
Recycling Time	Approx. 0.1 - 5.5 seconds
Weight	Approx. 455 g (without batteries)
