Maintenance
168
Lamp Replacement Procedure
1 Turn off the projector power and remove the power plug.
2 Loosen one screw and open the lamp cover in the direction of the arrow.
The lamp cover screw is attached to the lamp cover and designed to prevent it
from falling off.
3 Loosen the 3 screws on the inside of the lamp unit, then slowly pull out
the lamp unit in the direction of the arrow.
Even when the screws are loosened, they will not fall off the lamp unit.
4 Fully insert a new lamp unit and secure it with the 3 screws.
5 Close the lamp cover and tighten the screws.
6 Turn on the power. Bring up the menu and select [System settings] >
[Other settings] > [Lamp counter].
Screw
To Next Page
