Installation Procedure
Before setting up the projector, be sure to read “Before Installation” (P19).
Setting Up the Projector
■ Positioning the Projector in Front of the Screen
Place the projector in front of the screen.
■ Floor Installation
To adjust the projection position when the projector is installed on the floor, use the
lens shift function (P47, P61) to adjust up / down / left / right. You can also use the
adjustable feet to incline the projector upward by up to 6°.
For information about the relationship between screen size and projection distance,
refer to page 43.
■ Installation Tilted Upward
To correct keystone distortion when the projector is tilted upward (using adjustable
feet, for example), perform keystone correction (P67) or corner adjustment (P68).
• To avoid keystone distortion, install the
projector so that it is at right angles to the
screen.
• The screen must not be exposed to direct
sunlight or light from lighting equipment. In
a bright room, it is recommended that
lights be turned off, curtains be drawn, and
other steps taken to make the screen
easier to see.
Optical axis
Screen
Lens shift
Adjustable feet
