185
Product Specifications
Other Information Product Specifications
For details about the amount of lens shift, refer to “Lens Shift Function” on page 47.
Name Short Fixed Lens Ultra Long Zoom Lens
Model number RS-IL03WF RS-IL04UL
External View
Focal length 12.8 mm (0.5'') 53.6 - 105.6 mm (2.1 - 4.2'')
F number 2.0 2.34 - 2.81
Width 97.4 mm (3.8'') 97.4 mm (3.8'')
Height 106.5 mm (4.2'') 106.5 mm (4.2'')
Length 175.2 mm (6.9'') 184.2 mm (7.3'')
Weight 910 g (2.0 lbs) 940 g (2.1 lbs)
Zoom ratio – 1.95x
Projection
distance
0.7 - 5.2 m (2.3 - 17.1') 4.6 - 89.0 m (15.1 - 292.0')
Size 100
projection
distance
1.7 m (5.6') 7.6 - 14.9 m (24.9 - 48.9')
Name Wide Zoom Lens
Model number RS-IL05WZ
External View
Focal length 15.6 - 23.3 mm (6.0 - 9.0")
F number 2.09 - 2.34
Width 97.4 mm (3.8")
Height 106.5 mm (4.2")
Length 180.3 mm (7.1")
Weight 905 g (2.0 lbs)
Zoom ratio 1.5x
Projection
distance
0.9 - 19.5 m (3.0 - 64.0')
Size 100
projection
distance
2.2 - 3.2 m (7.2 - 10.5')
To Next Page
