4
}
}
06E COMPRESSORS
06ER 3 99 3 0 A – (RP)**
Model = 0, Package = 1 or 9, A = Shipped Without Oil
Design Variable:
New Compressors:
0 = OEM Model
1 = Carrier A/C Model
2 = Old Design Refrigeration Valve Plates
6 = Carrier A/C Model
9 = Cemak Model
Service Compressors:
2 = New Manufactured (A/C)
4 = Remanufactured (Low Temp.)
6 = Remanufactured (A/C)
7 = Remanufactured (Med Temp.)
Electrical Characteristics (XL and PW Start, Unless Noted):
0 = 208/230-3-60
1 = 575-3-60
3 = 208/230/460-3-50/60 (460v XL Only)
4 = 200-3-60
5 = 230-3-60
6 = 400/460-3-50/60
8 = 230-3-50
9 = 220/380-3-60
Displacement (in Cfm at 1750 rpm)
Design Configuration
0, 1, 2 = Models With Oil
3, 4, 5 = Models Without Oil
7 = 1 Unloader, Suction Cut-off, Oil-less (ER, EM Only)
8 = Special Order
Compressor Type:
STD* REV†
06EA 06EF Compressor - A/C Duty No Unloading
06EB 06EJ Compressor - A/C Duty 1-Step Elec.
06EC 06EK Compressor - A/C Duty 2-Step Elec.
06ED 06EL Compressor - A/C Duty 1-Step Press.
06EE 06EN Compressor - A/C Duty 2-Step Press.
06E2 06E6 Compressor - A/C Duty 1-Step Elec.
06E3 06E7 Compressor - A/C Duty 2-Step Elec.
06E4 06E8 Compressor - A/C Duty 1-Step Press.
06E5 06E9 Compressor - A/C Duty 2-Step Press.
06EM - Compressor - Refrig. Duty Med Temp.
06ER - Compressor - Refrig. Duty Low Temp.
06ET - Serv. Compressor A/C Duty Replaces 06E2,3,4,5,6,7,8, and 9.
Compressor has 1 stage of suction cut-off unloading.
06EX - Serv. Compressor A/C Duty Replaces 06EA,B,C,D,E,F,J,K,L, and N.
Compressor has 1 stage of Bypass unloading.
06EY - Serv. Compressor Refrig. Duty Replaces 06ER
06EZ - Serv. Compressor Refrig. Duty Replaces 06EM
* Standard Center Cylinder Head.
† Reversed Center Cylinder Head.
Service compressors shipped with reverse center head have the letter “R” after the
serial number on the shipping box.
**Refrigeration Partner.
Information in shaded area is no longer available in standard factory production.
Hot Gas Bypass
Unloading
Suction Cut-Off
Unloading
Y = SMART Unloading Model
S = Oil Sensor Block and OPSS Sensor
