3.18 — Compressor Mounting Data
Mounting packages are available to mount individual com-
pressors. Package contains mounting springs, threaded studs,
snubbers, spring cups, nuts, and washers for (1) compressor.
COMPRESSOR MOUNTING PLATE PACKAGE
No. 06EA660096
This universal mounting plate will accommodate any size
06D, 06E, and 06CC compressor. Mount plate to existing
base and mount the Carlyle compressor to the plate. Package
includes pre-drilled mounting plate, spacers, and template.
3.19 — Compressor Service Valves (06D, E, CC)
* Valve packages consist of (1) service shut-off valve and required gasket and mounting
bolts.
NOTE: Sensor valve packages required with Carlyle Sentinel module. Adapter for 06CC
Liquid Injection Port PN 2TA1004.
3.20 — Service Valve Gaskets (06D, E, CC)
* Service package contains 12 gaskets.
MOUNTING PACKAGE NUMBER USE WITH BODY STYLE
06DA660058 06d 2-cyl
06DA660056 06D 4-cyl
06DA660057 06D, 06CC (16 to 41 Cfm) 6-cyl
06EA660089 06E 4 and 6-cyl and 06CC (50 to 99 Cfm)
VALVE
PACKAGE NO.*
SENSOR VALVE
PACKAGE*
INCLUDES
ODS (in.)
BOLT HOLE
SPACING
(in.)
VALVE
NUMBER
06DA660060 06EA900412 5/8 brass 1-5/8 EN32AA250
06DA660061 06EA900422 7/8 brass 1-5/8 EN07AA271
06DA660062 06EA9004327/8 brass 1-3/4 EN07AA284
06DA660063 06EA900442 1-1/8 brass 2-1/2 sq. EN07EA033
06DA660064 06EA900452 1-1/8 brass 1-3/4 EN07AA348
06DA660065 06EA900462 1-3/8 brass 2-1/2 sq. EN07EA039
06EA660090 06EA900472 1-5/8 brass 2-1/2 sq. EN07EA041
06EA660091 — 2-1/8 brass 3-1/16 sq. EM13RA516
06EA660164 06EA9004822-1/8 steel 3-1/16 sq. EN07EA510
DESCRIPTION
FIBER VALVE GASKET
PACKAGE*
METAL VALVE GASKET
PACKAGE
2-bolt 1-5/8-in. spacing 6D23-1421 06DA504143
2-bolt 1-3/4-in. spacing 6D40-1131 06DA504163
4-bolt 2-1/2-in. spacing 6D68-1131 06DA504153
Circular, No Holes 6G65-1061 —
