3.17 — Crankcase Heater Data
Crankcase heaters help reduce refrigerant migration to the
compressor during shut-down. Crankcase heaters are
designed to raise the temperature in the compressor oil com-
partment approximately 15 to 25°F (8 to 14°C). Carlyle rec-
ommends crankcase heaters be wired so the heater is
energized only when the compressor shuts off. Crankcase
heaters should be “ON” initially for 24 hours before starting
the compressor. All HFC/POE applications require a crank-
case heater.
STRAP-ON HEATERS:
Mounted externally to the underside of the stamp steel bot-
tom plate. Install axially using (2) bottom plate bolts plus
brackets and screws in package. Used on 06D( )808, 109,
013, 313, and 316 compressors. All strap-on heaters are 50
watts.
INSERTION HEATERS:
Insert into cast well (hole) in cast iron bottom plate. Circular
clip with barbs secures heater. Used on 06D( )718, 818, and
820 4-cylinder compressors, all 6-cylinder 06D compres-
sors, all 06E and all 06CC compressors. Insertion heaters are
available in 125 and 180 watt sizes.
NOTES:
1. Insertion heaters use AS8IVF056 tubular clip.
2. Thermal grease is provided and must be used with 180 watt heaters (grease packet
PN 38AQ680001).
CRANKCASE HEATER PACKAGES
CRANKCASE
HEATER
PACKAGE
TYPE
HEATER
NUMBER
VOLTAGE WATTS
CONDUIT
LENGTH
in. (cm)
WIRE
LENGTH
in. (cm)
06DA660091
06DA660092
Strap-on
Strap-on
HT33AK300
HT33BK310
115
230
50
50
24 (61)
24 (61)
39 (99)
39 (99)
06EA660165
06EA660167
Insertion
Insertion
HT36DM132
HT36DM134
115
115
180
180
19 (48)
52 (132)
24 (61)
73 (185)
06EA660166 Insertion HT36DM43223018019 (48) 24 (61)
06EA660168
06EA660076
Insertion
Insertion
HT36DM434
HT36DL480
230
480
180
12
5
52 (132)
—
73 (185)
24 (61)
