Carlyle 06CC User Manual

67
3.3 — 06CC Series Compressors - Physical Data (Page 2 of 2) LEGEND CFH - Cubic ft per hour L/H - Liters per hour L/M - Liters per minute
CARRIER/
CARLYLE
MODEL
NUMBER
MOTOR
SIZE
DISPLACEMENT AT 1750 RPM
NO. OF CYL
BORE STROKE OIL CHARGE
NET
WEIGHT
BODY
SIZE
HP kW CFM L/M CFH
L/H
(1,000)
in. mm in. mm Pints Liters Lb Kg
06CC016... (g) 5 3.7 15.9 450 954 27.01 6 2 50.8 1 1/4 31.8 9.5 4.5 330 150 D
06CC017... 5 3.7 15.9 450 954 27.01 6 2 50.8 1 1/4 31.7 9.5 4.5 330 150 D
06CC018... (g) 5 3.7 18.3 518 1100 31.09 6 2 50.8 1 15/32 37.3 9.5 4.5 325 147 D
06CC124... 6 1/2 4.9 23.9 677 1435 40.60 6 2 50.8 1 1/4 31.8 9.5 4.5 335 152 D 06CC125... 6 1/2 4.9 23.9 677 1435 40.60 6 2 50.8 1 1/4 31.8 9.5 4.5 330 150 D 06CC228... 7 1/2 5.6 28.0 793 1680
47.57 6 2 50.8 1 15/32 37.3 9.5 4.5 340 154 D
06CC337... 10 7.5 37.1 1050 2225 63.03 6250.8 1 15/16 49.2 9.5 4.5 345 156 D
06CC550... (g) 15 11.2 50.3 1424 3016 85.45 6 2 11/16 68.3 1 63/64 50.4 19 9.0 545 247 E
06CC665... 20 14.9 68.3 1934 4096 116.0 6 2 11/16 68.3 1 63/64 50.4 19 9.0 555 252 E 06CC675... 20 14.9 75.4 2135 4524 128.1 6 2 11/16 68.3 2 3/16 55.6 19 9.0 555 252 E 06CC899... 3022.499.02803 5940 168.2 6 2 11/16 68.3 2 7/8 73.0 19 9.0 580263 E
