Table 4C — Unit Electrical Data, 30GT230-420
30GT
UNIT
SIZE
VOLTAGE
MODULE A
Standard Condenser Fan High-Static Condenser Fan
Nameplate
V-Hz
(3 Phase)
Supplied*
MCA MOCP
Rec
Fuse Size
ICF
MCA MOCP
Rec
Fuse Size
ICF
Min Max XL PW XL PW XL PW XL PW
230
208/230-60 187 253 664.2 800 800 800 1165.1 889.1 755.8 800 800 800 1256.7 980.7
460-60 414 506 312.9 350 350 350 576.1 438.1 334.9 400 400 400 608.1 470.1
575-60 518 633 272.3 300 300 300 440.9 344.9 290.3 350 350 350 458.9 362.9
380-60 342 418 359.9 400 400 400 641.6 489.6 394.9 450 450 450 676.6 524.6
346-50 325 380 465.1 500 450 450 764.8 604.8 508.1 600 500 500 807.8 647.8
380/415-50 342 440 377.9 400 400 400 641.0 503.0 416.9 450 450 450 680.0 542.0
245
208/230-60 187 253 664.2 800 800 800 1165.1 889.1 755.8 800 800 800 1256.7 980.7
460-60 414 506 312.9 350 350 350 576.1 438.1 334.9 400 400 400 608.1 470.1
575-60 518 633 272.3 300 300 300 440.9 344.9 290.3 350 350 350 458.9 362.9
380-60 342 418 359.9 400 400 400 641.6 489.6 394.9 450 450 450 676.6 524.6
346-50 325 380 465.1 500 450 450 764.8 604.8 508.1 600 500 500 807.8 647.8
380/415-50 342 440 377.9 400 400 400 641.0 503.0 416.9 450 450 450 680.0 542.0
255
208/230-60 187 253 664.2 800 800 800 1165.1 889.1 755.8 800 800 800 1256.7 980.7
460-60 414 506 312.9 350 350 350 576.1 438.1 334.9 400 350 400 608.1 470.1
575-60 518 633 272.3 300 300 300 440.9 344.9 290.3 350 300 350 458.9 362.9
380-60 342 418 359.9 400 400 400 641.6 489.6 394.9 450 400 450 676.6 524.6
346-50 325 380 465.1 500 450 450 764.8 604.8 508.1 600 450 500 807.8 647.8
380/415-50 342 440 377.9 400 400 400 641.0 503.0 416.9 450 400 450 680.0 542.0
270
208/230-60 187 253 727.5 800 800 800 1098.9 896.9 819.1 1000 1000 1000 1190.5 988.5
460-60 414 506 323.5 350 350 350 518.0 417.0 355.5 400 400 400 550.0 449.0
575-60 518 633 294.6 300 350 350 418.5 348.5 312.6 350 350 350 436.5 366.5
380-60 342 418 387.8 400 450 450 598.0 486.0 422.8 450 350 450 633.0 521.0
346-50 325 380 472.1 500 500 500 771.8 611.8 515.1 600 600 600 814.8 654.8
380/415-50 342 440 387.3 450 450 450 650.4 512.4 426.3 450 450 450 689.4 551.4
290
208/230-60 187 253 800.0 800 1000 1000 1301.5 1025.5 910.6 1000 1000 1000 1411.5 1135.5
460-60 414 506 368.2 400 400 400 631.4 493.4 406.2 450 450 450 669.4 531.4
575-60 518 633 325.9 350 350 350 494.5 398.5 347.5 400 400 400 516.1 420.1
380-60 342 418 432.5 500 450 450 714.2 562.2 474.5 500 500 500 756.2 604.2
346-50 325 380 554.1 600 600 600 853.8 693.8 605.7 1000 700 700 905.4 745.4
380/415-50 342 440 515.7 500 500 500 669.4 575.3 497.0 500 600 600 760.1 622.1
315
208/230-60 187 253 890.4 1000 1000 1000 1391.3 1115.3 1000.0 1000 1200 1200 1501.3 1225.3
460-60 414 506 413.1 450 450 450 676.3 538.3 451.1 450 500 500 714.3 576.3
575-60 518 633 362.5 400 400 400 531.1 435.1 384.1 450 400 400 552.7 456.7
380-60 342 418 479.3 500 500 500 761.0 609.0 521.3 600 600 600 803.0 651.0
346-50 325 380 567.5 600 600 600 867.2 707.2 619.1 700 700 700 918.8 758.8
380/415-50 342 440 474.5 500 500 500 737.6 599.6 521.3 500 600 600 784.4 646.4
330
208/230-60 187 253 727.5 800 800 800 1098.9 896.9 819.1 1000 1000 1000 1190.5 988.5
460-60 414 506 323.5 350 350 350 518.0 417.0 355.5 400 400 400 550.0 449.0
575-60 518 633 294.6 300 350 350 418.5 348.5 312.6 350 350 350 436.5 366.5
380-60 342 418 387.8 400 450 450 598.0 486.0 422.8 450 450 450 633.0 521.0
230-50 207 253 677.7 700 800 800 1088.1 870.1 735.7 800 800 800 1146.1 928.1
346-50 325 380 472.1 500 500 500 771.8 611.8 515.1 600 600 600 814.8 654.8
380/415-50 342 440 387.6 450 450 450 650.4 512.4 426.3 450 450 450 689.4 551.4
360
208/230-60 187 253 800.0 800 1000 1000 1301.5 1025.5 910.6 1000 1000 1000 1411.5 1135.5
460-60 414 506 368.2 400 400 400 631.4 493.4 406.2 450 450 450 669.4 531.4
575-60 518 633 325.9 350 350 350 494.5 398.5 347.5 400 400 400 516.1 420.1
380-60 342 418 432.5 500 450 450 714.2 562.2 474.5 500 500 500 756.2 604.2
230-50 207 253 749.9 800 800 800 1160.3 942.3 819.5 700 1000 1000 1229.9 1011.9
346-50 325 380 554.1 600 600 600 853.8 693.8 605.7 1000 700 700 905.4 745.4
380/415-50 342 440 515.7 500 500 500 669.4 575.3 497.0 500 600 600 760.1 622.1
390
208/230-60 187 253 890.4 1000 1000 1000 1391.3 1115.3 1000.0 1000 1200 1200 1501.3 1225.3
460-60 414 506 413.1 450 450 450 676.3 538.3 451.1 500 500 500 714.3 576.3
575-60 518 633 362.5 400 400 400 531.1 435.1 384.1 400 400 400 552.7 456.7
380-60 342 418 479.3 500 500 500 761.0 609.0 521.3 600 600 600 803.0 651.0
230-50 207 253 796.2 800 800 800 1206.6 988.3 865.8 1000 800 800 1276.2 1058.2
346-50 325 380 567.5 600 600 600 867.2 707.2 619.1 700 700 700 918.8 758.8
380/415-50 342 440 474.5 500 500 500 737.6 599.6 521.3 600 600 600 784.4 646.4
420
208/230-60 187 253 890.4 1000 1000 1000 1391.3 1115.3 1000.0 1000 1200 1200 1501.3 1225.3
460-60 414 506 413.1 450 450 450 676.3 538.3 451.1 500 500 500 714.3 576.3
575-60 518 633 362.5 400 400 400 531.1 435.1 384.1 400 400 400 552.7 456.7
380-60 342 418 479.3 500 500 500 761.0 609.0 521.3 600 600 600 803.0 651.0
230-50 207 253 796.2 800 800 800 1206.6 988.3 865.8 1000 800 800 1276.2 1058.2
346-50 325 380 567.5 600 600 600 867.2 707.2 619.1 700 700 700 918.8 758.8
380/415-50 342 440 474.5 500 500 500 737.6 599.6 521.3 600 600 600 784.4 646.4
NOTE: See legend and notes on page 33.
