Table 6B — Compressor Electrical Data, 30GT130-210
30GT
UNIT
SIZE
NAMEPLATE
V-Hz
(3 Phase)
COMPRESSOR NUMBERS
A1 A2 A3 A4 B1 B2 B3
RLA LRA RLA LRA RLA LRA RLA LRA RLA LRA RLA LRA RLA LRA
130-XL
208/230-60 107.7 506 151.3 690 — —
——
107.7 506 151.3 690
——
460-60 46.8 253 64.5 345 — — 46.8 253 65.4 345
575-60 41.7 176 57.1 176 — — 41.7 176 57.1 176
380-60 55.8 280 80.2 382 — — 55.8 280 80.2 382
346-50 46.8 259 55.8 294 55.8 294 80.2 400 80.2 400
230-50 77.0 342 87.9 366 87.9 366 107.7 545 107.7 545
380/415-50 44.9 223 46.8 253 46.8 253 65.5 345 65.5 345
130-PW
208/230-60 107.7 304 151.3 414 — —
——
107.7 304 151.3 414
——
460-60 46.8 152 65.4 207 — — 46.8 152 65.4 207
575-60 41.7 106 57.1 144 — — 41.7 106 57.1 144
380-60 55.8 168 80.2 230 — — 55.8 168 80.2 230
346-50 46.8 155 55.8 155 55.8 155 80.2 240 80.2 240
230-50 77.0 206 87.9 220 87.9 220 107.7 327 107.7 327
380/415-50 44.9 134 65.5 207 46.8 152 65.5 207 65.5 207
150-XL
208/230-60 89.8 446 89.8 446 89.8 446
——
151.3 690 151.3 690
——
460-60 44.9 223 44.9 223 44.9 223 65.4 345 65.4 345
575-60 36.6 164 36.6 164 36.6 164 57.1 240 57.1 240
380-60 46.8 247 46.8 247 46.8 247 80.2 382 80.2 382
346-50 80.2 400 80.2 400 80.2 400 80.2 400 80.2 400
230-50 107.7 545 107.7 545 107.7 545 107.7 545 107.7 545
380/415-50 65.5 345 65.5 345 65.5 345 65.5 345 65.5 345
150-PW
208/230-60 89.8 268 89.8 268 89.8 268
——
151.3 414 151.3 414
——
460-60 44.9 134 44.9 134 44.9 134 65.4 207 65.4 207
575-60 36.6 99 36.6 99 36.6 99 57.1 144 57.1 144
380-60 46.8 149 46.8 149 46.8 149 80.2 230 80.2 230
346-50 80.2 240 80.2 240 80.2 240 80.2 240 80.2 240
230-50 107.7 268 107.7 268 107.7 268 107.7 327 107.7 327
380/415-50 65.5 207 65.5 207 65.5 207 65.5 207 65.5 207
170-XL
208/230-60 107.7 506 107.7 506 107.7 506
——
107.7 506 107.7 506 107.7 506
460-60 46.8 253 46.8 253 46.8 253 46.8 253 46.8 253 46.8 253
575-60 41.7 176 41.7 176 41.7 176 41.7 176 41.7 176 41.7 176
380-60 55.8 280 55.8 280 55.8 280 55.8 280 55.8 280 55.8 280
346-50 55.8 294 55.8 294 80.2 400 55.8 294 80.2 400 80.2 400
230-50 87.9 366 87.9 366 107.7 545 87.9 366 107.7 545 107.7 545
380/415-50 46.8 253 46.8 253 65.5 345 46.8 253 65.5 345 65.5 345
170-PW
208/230-60 107.7 304 107.7 304 107.7 304
——
107.7 304 107.7 304 107.7 304
460-60 46.8 152 46.8 152 46.8 152 46.8 152 46.8 152 46.8 152
575-60 41.7 106 41.7 106 41.7 106 41.7 106 41.7 106 41.7 106
380-60 55.8 168 55.8 168 55.8 168 55.8 168 55.8 168 55.8 168
346-50 55.8 177 55.8 177 80.2 240 55.8 177 80.2 240 80.2 240
230-50 87.9 220 87.9 220 107.7 327 87.9 220 107.7 327 107.7 327
380/415-50 46.8 152 46.8 152 65.5 207 46.8 152 65.5 207 65.5 207
190-XL
208/230-60 89.8 446 107.7 506 151.3 690
——
89.8 446 107.7 506 151.3 690
460-60 44.9 223 46.8 253 65.4 345 44.9 223 46.8 253 65.4 345
575-60 36.6 164 41.7 176 57.1 240 36.6 164 41.7 176 57.1 240
380-60 46.8 247 55.8 280 80.2 382 46.8 247 55.8 280 80.2 382
346-50 80.2 400 80.2 400 80.2 400 80.2 400 80.2 400 80.2 400
230-50 107.7 545 107.7 545 107.7 545 107.7 545 107.7 545 107.7 545
380/415-50 65.5 345 65.5 345 65.5 345 65.5 345 65.5 345 65.5 345
190-PW
208/230-60 89.8 268 107.7 304 151.3 414
——
89.8 268 107.7 304 151.3 414
460-60 44.9 134 46.8 152 65.4 207 44.9 134 46.8 152 65.4 207
575-60 36.6 99 41.7 106 57.1 144 36.6 99 41.7 106 57.1 144
380-60 46.8 149 55.8 168 80.2 230 46.8 149 55.8 168 80.2 230
346-50 80.2 240 80.2 240 80.2 240 80.2 240 80.2 240 80.2 240
230-50 107.7 327 107.7 327 107.7 327 107.7 327 107.7 327 107.7 327
380/415-50 65.5 207 65.5 207 65.5 207 65.5 207 65.5 207 65.5 207
210-XL
208/230-60 89.8 446 89.8 446 89.8 446 107.7 506 107.7 506 151.3 690 151.3 690
460-60 44.9 223 44.9 223 44.9 223 46.8 253 46.8 253 65.4 345 65.4 345
575-60 36.6 164 36.6 164 36.6 164 41.7 176 41.7 176 57.1 240 57.1 240
380-60 46.8 247 46.8 247 46.8 247 55.8 280 55.8 280 80.2 382 80.2 382
346-50 46.8 259 46.8 259 80.2 400 80.2 400 80.2 400 80.2 400 80.2 400
230-50 77.0 342 77.0 342 107.7 545 107.7 545 107.7 545 107.7 545 107.7 545
380/415-50 44.9 223 44.9 223 65.5 345 65.5 345 65.5 345 65.5 345 65.5 345
210-PW
208/230-60 89.8 268 89.8 268 89.8 268 107.7 304 107.7 304 151.3 414 151.3 414
460-60 44.9 134 44.9 134 44.9 134 46.8 152 46.8 152 65.4 207 65.4 207
575-60 36.6 99 36.6 99 36.6 99 41.7 106 41.7 106 57.1 144 57.1 144
380-60 46.8 149 46.8 149 46.8 149 55.8 168 55.8 168 80.2 230 80.2 230
346-50 46.8 155 46.8 155 80.2 240 80.2 240 80.2 240 80.2 240 80.2 240
230-50 77.0 206 77.0 206 107.7 327 107.7 327 107.7 327 107.7 327 107.7 327
380/415-50 44.9 134 44.9 134 65.5 207 65.5 207 65.5 207 65.5 207 65.5 207
NOTE: See legend and notes on page 33.
