Table 5 — Control Circuit
UNIT POWER SUPPLY
(V-Ph-Hz)
CONTROL POWER AMPS
V-Ph-Hz Min Max
080-110 and
230B-315B Units
130-210,230A-315A, and
330A/B-420A/B Units
With Cooler
Heater
Without
Cooler Heater
With Cooler
Heater
Without
Cooler Heater
203/230-3-60 115-1-60 104 127 30 30 30 30
460-3-60 115-1-60 104 127 30 30 30 30
575-3-60 115-1-60 104 127 30 30 30 30
380-3-60 230-1-60 207 254 15 5 15 10
346-3-50 230-1-50 198 254 15 5 15 10
230-3-50** 230-1-50 198 254 — — 15 10
380/415-3-50 230-1-50 198 254 15 5 15 10
See legend and notes on page 33.
Table 6A — Compressor Electrical Data, 30GT080-110
30GT
UNIT
SIZE
NAMEPLATE
V-Hz (3 Phase)
COMPRESSOR NUMBERS
A1 A2 B1 B2
RLA LRA RLA LRA RLA LRA RLA LRA
080-XL
208/230-60 106.4 506 67.9 345 147.7 690 — —
460-60 46.8 253 34.6 173 65.4 345 — —
575-60 40.4 176 28.8 120 57.1 276 — —
380-60 52.6 280 34.6 191 78.8 382 — —
346-50 44.9 247 79.5 382 79.5 382 — —
380/415-50 43.6 223 65.4 345 65.4 345 — —
080-PW
208/230-60 106.4 304 67.9 207 147.4 414 — —
460-60 48.7 152 33.3 104 67.9 207 — —
575-60 33.3 106 28.2 72 53.8 165 — —
380-60 53.8 168 33.3 115 79.5 229 — —
346-50 44.9 148 79.5 229 79.5 229 — —
380/415-50 44.9 134 67.9 207 67.9 207 — —
090-XL
208/230-60 89.7 446 67.9 345 89.7 446 89.7 446
460-60 43.6 223 34.6 173 43.6 223 43.6 223
575-60 36.5 164 28.8 120 36.5 164 36.5 164
380-60 45.5 247 34.6 191 45.5 247 45.5 247
346-50 44.9 247 79.5 382 44.9 247 53.8 280
380/415-50 43.6 223 65.4 345 43.6 223 46.8 280
090-PW
208/230-60 89.7 268 67.9 207 89.7 268 89.7 268
460-60 44.9 134 33.3 104 44.9 134 44.9 134
575-60 33.3 98 28.2 72 33.3 98 33.3 98
380-60 44.9 148 33.3 115 44.9 148 44.9 148
346-50 44.9 148 79.5 229 44.9 148 53.8 168
380/415-50 43.6 134 67.9 207 44.9 134 48.7 152
100-XL
208/230-60 89.7 446 106.4 506 89.7 446 106.4 506
460-60 43.6 223 46.8 253 43.6 223 46.8 253
575-60 36.5 164 40.4 176 36.5 164 40.4 176
380-60 45.5 247 52.6 280 45.5 247 52.6 280
346-50 44.9 247 79.5 382 44.9 247 79.5 382
380/415-50 43.6 223 65.4 345 43.6 223 65.4 345
100-PW
208/230-60 89.7 268 106.4 304 89.7 268 106.4 304
460-60 44.9 134 48.7 152 44.9 134 48.7 152
575-60 33.3 98 33.3 106 33.3 98 33.3 106
380-60 44.9 148 53.8 168 44.9 148 53.8 168
346-50 44.9 148 79.5 229 44.9 148 79.5 229
380/415-50 44.9 134 67.9 207 44.9 134 67.9 207
110-XL
208/230-60 89.7 446 147.4 690 89.7 446 106.4 506
460-60 43.6 223 65.4 345 43.6 223 46.8 253
575-60 36.5 164 57.1 276 36.5 164 40.4 176
380-60 45.5 247 78.8 382 45.5 247 52.6 280
346-50 79.5 382 79.5 229 79.5 382 79.5 382
380/415-50 65.4 345 65.4 207 65.4 345 65.4 345
110-PW
208/230-60 89.7 268 147.4 414 89.7 268 106.4 304
460-60 44.9 134 67.9 207 44.9 134 48.7 152
575-60 33.3 98 53.8 165 33.3 98 33.3 106
380-60 44.9 148 79.5 229 44.9 148 53.8 168
346-50 79.5 229 79.5 229 79.5 229 79.5 229
380/415-50 67.9 207 67.9 207 67.9 207 67.9 207
NOTE: See legend and notes on page 33.
36
