Table 6C — Compressor Electrical Data, 30GT230-420
30GT
UNIT
SIZE
NAMEPLATE
V-Hz
(3 Phase)
MODULE A
Compressor Numbers
A1 A2 A3 A4 B1 B2 B3
RLA LRA RLA LRA RLA LRA RLA LRA RLA LRA RLA LRA RLA LRA
230-XL
208/230-60 89.8 446 89.8 446 89.8 446
——
151.3 690 151.3 690
——
460-60 44.9 223 44.9 223 44.9 223 65.4 345 65.4 345
575-60 36.6 164 36.6 164 36.6 164 57.1 240 57.1 240
380-60 46.8 247 46.8 247 46.8 247 80.2 382 80.2 382
346-50 80.2 400 80.2 400 80.2 400 80.2 400 80.2 400
380/415-50 65.5 345 65.5 345 65.5 345 65.5 345 65.5 345
230-PW
208/230-60 89.8 268 89.8 268 89.8 268
——
151.3 414 151.3 414
——
460-60 44.9 134 44.9 134 44.9 134 65.4 207 65.4 207
575-60 36.6 99 36.6 99 36.6 99 57.1 144 57.1 144
380-60 46.8 149 46.8 149 46.8 149 80.2 230 80.2 230
346-50 80.2 240 80.2 240 80.2 240 80.2 240 80.2 240
380/415-50 65.5 207 65.5 207 65.5 207 65.5 207 65.5 207
245-XL
208/230-60 89.8 446 89.8 446 89.8 446
——
151.3 690 151.3 690
——
460-60 44.9 223 44.9 223 44.9 223 65.4 345 65.4 345
575-60 36.6 164 36.6 164 36.6 164 57.1 240 57.1 240
380-60 46.8 247 46.8 247 46.8 247 80.2 382 80.2 382
346-50 80.2 400 80.2 400 80.2 400 80.2 400 80.2 400
380/415-50 65.5 345 65.5 345 65.5 345 65.5 345 65.5 345
245-PW
208/230-60 89.8 268 89.8 268 89.8 268
——
151.3 414 151.3 414
——
460-60 44.9 134 44.9 134 44.9 134 65.4 207 65.4 207
575-60 36.6 99 36.6 99 36.6 99 57.1 144 57.1 144
380-60 46.8 149 46.8 149 46.8 149 80.2 230 80.2 230
346-50 80.2 240 80.2 240 80.2 240 80.2 240 80.2 240
380/415-50 65.5 207 65.5 207 65.5 207 65.5 207 65.5 207
255-XL
208/230-60 89.8 446 89.8 446 89.8 446
——
151.3 690 151.3 690
——
460-60 44.9 223 44.9 223 44.9 223 65.4 345 65.4 345
575-60 36.6 164 36.6 164 36.6 164 57.1 240 57.1 240
380-60 46.8 247 46.8 247 46.8 247 80.2 382 80.2 382
346-50 80.2 400 80.2 400 80.2 400 80.2 400 80.2 400
380/415-50 65.5 345 65.5 345 65.5 345 65.5 345 65.5 345
255-PW
208/230-60 89.8 268 89.8 268 89.8 268
——
151.3 414 151.3 414
——
460-60 44.9 134 44.9 134 44.9 134 65.4 207 65.4 207
575-60 36.6 99 36.6 99 36.6 99 57.1 144 57.1 144
380-60 46.8 149 46.8 149 46.8 149 80.2 230 80.2 230
346-50 80.2 240 80.2 240 80.2 240 80.2 240 80.2 240
380/415-50 65.5 207 65.5 270 65.5 207 65.5 207 65.5 207
270-XL
208/230-60 107.7 506 107.7 506 107.7 506
——
107.7 506 107.7 506 107.7 506
460-60 46.8 253 46.8 253 46.8 253 46.8 253 46.8 253 46.8 253
575-60 41.7 176 41.7 176 41.7 176 41.7 176 41.7 176 41.7 176
380-60 55.8 280 55.8 280 55.8 280 55.8 280 55.8 280 55.8 280
346-50 55.8 294 55.8 294 80.2 400 55.8 294 80.2 400 80.2 400
380/415-50 46.8 253 46.8 253 65.5 345 46.8 253 65.5 345 65.5 345
270-PW
208/230-60 107.7 304 107.7 304 107.7 304
——
107.7 304 107.7 304 107.7 304
460-60 46.8 152 46.8 152 46.8 152 46.8 152 46.8 152 46.8 152
575-60 41.7 106 41.7 106 41.7 106 41.7 106 41.7 106 41.7 106
380-60 55.8 168 55.8 168 55.8 168 55.8 168 55.8 168 55.8 168
346-50 55.8 177 55.8 177 80.2 240 55.8 177 80.2 240 80.2 240
380/415-50 46.8 152 46.8 152 46.8 207 46.8 152 65.5 207 65.5 207
290-XL
208/230-60 89.8 446 107.7 506 151.3 690
——
89.8 446 107.7 506 151.3 690
460-60 44.9 223 46.8 253 65.4 345 44.9 223 46.8 253 65.4 345
575-60 36.6 164 41.7 176 57.1 240 36.6 164 41.7 176 57.1 240
380-60 46.8 247 55.8 280 80.2 382 46.8 247 55.8 280 80.2 382
346-50 80.2 400 80.2 400 80.2 400 80.2 400 80.2 400 80.2 400
380/415-50 65.5 345 65.5 345 65.5 345 65.5 345 65.5 345 65.5 345
290-PW
208/230-60 89.8 268 107.7 304 151.3 414
——
89.8 268 107.7 304 151.3 414
460-60 44.9 134 46.8 152 65.4 207 44.9 134 46.8 152 65.4 207
575-60 36.6 99 41.7 106 57.1 144 36.6 99 41.7 106 57.1 144
380-60 46.8 149 55.8 168 80.2 230 46.8 149 55.8 168 80.2 230
346-50 80.2 240 80.2 240 80.2 240 80.2 240 80.2 240 80.2 240
380/415-50 65.5 207 65.5 207 65.5 207 65.5 207 65.5 207 65.5 207
NOTE: See legend and notes on page 33.
