Carrier 30HXC User Manual

10


 A    E F
 2558 980 1800 2200 1000 385
110 2565 980 1850 2200 1000 385
120-130-140-155 3275 980 1816 2990 1000 689
 3275 980 1940 2990 1000 689
NOTE: Refer to the certied dimensional drawings supplied
with the unit, when designing an installation.
30HXC-080
30HXC-090
30HXC-100
30HXC-110
AD
B
600
500
4
700
4
3
C
E
3
3
F
1
2

 Alldimensionsareinmm.
Evaporator
Condenser
Clearances required for operation and maintenance
 Clearancesrequiredforheatexchangertuberemoval.ClearancesD
andEcanbeeitherontheleftorontherighthandside.
Water inlet
Water outlet
Power supply
a
b
c
d
