Carrier 30HXC User Manual

41

    
Low-temperaturebrinesolution 6 Lowtemperatureglycolsolutionproduction
down to -10 °C with ethylene glycol
Coversspecicapplicationssuchasicestorage
and industrial processes
090,110,130,155,175,
200, 230, 260, 310, 345
IP44Celectricalprotectionlevel 20 Controlboxthightnessreinforced Permits unit installation in more severe
envrionments
080-375
Tropicalisation 22 Unitcontrolboxsuitablefortropicalclimates Reducedrelativehumidityinthecontrolboxesfor
operation in tropical climates (warm and humid)
080-375
Soft Starter 25 Electronic starter on each compressor Reduced start-up current 200-375
Cu/Ni condensers 33 Condensertubesandtubessheetsin90-10
Copper/Nickel alloy
Allows applications with sea water 080-375
Cu/Ni condensers + Sakaphen
coatedwaterboxes
34A Condensertubesandtubessheetsin90-10
Copper/Nickel alloy and Sakaphen treatment
insidewaterboxes
Allows applications with sea water, improved
durabilityofwaterboxes
080-375
Unitsuppliedintwoassembled
parts
51 Theunitisequippedwithangesthatallow
disassemblyoftheunitonsite
Facilitates installation in plant rooms with limited
access
080-375
460-3-60 power supply 60 Power supply of 460 V-3 ph-60 Hz Permits unit connection to a power network with
speciccharacteristics
080-375
380-3-60 power supply 61 Power supply of 380 V-3 ph-60 Hz Permits unit connection to a power network with
speciccharacteristics
080-375
Evap.pumppower/controlcircuit 84 Unitequippedwithanelectricalpowerand
control circuit for one pump evaporator side
Quickandeasyinstallation:thecontrolofxed
speedpumpsisembeddedintheunitcontrol
080-375
Evap.dualpumpspower/control
circuit
84D Unitequippedwithanelectricalpowerand
control circuit for two pumps evaporator side
Quickandeasyinstallation:thecontrolofxed
speedpumpsisembeddedintheunitcontrol
080-375
Cond.pumppower/controlcircuit 84R Unitequippedwithanelectricalpowerand
control circuit for one pump condenser side
Quickandeasyinstallation:thecontrolofxed
speedpumpsisembeddedintheunitcontrol
080-375
Compressor suction valve 92 Valve set for the compressor suction side to
isolate it in the refrigerant circuit
Simpliedserviceandmaintenance 080-375
Evaporator with one pass less 100C Evaporatorwithonepassonthewaterside.
Evaporatorinletandoutletonoppositesides.
Easytoinstall,dependingonsite.Reduced
pressure drops
080-375
Condenser with one pass less 102C Condenserwithonepassonthewaterside.
Condenserinletandoutletonoppositesides.
Easytoinstall,dependingonsite.Reduced
pressure drops
080-375
21barevaporator 104 Reinforced evaporator for extension of the
maximum water-side service pressure to 21
bar(standard10bar)
Covers applications with a high water column
evaporatorside(typicallyhighbuildings)
080-375
21barcondenser 104A Reinforced condenser for extension of the
maximum water-side service pressure to 21
bar(standard10bar)
Covers applications with a high water column
condenserside(typicallyhighbuildings)
080-375
Reversed evaporator water
connections
107 Evaporator with reversed water inlet/outlet Easyinstallationonsiteswithspecic
requirements
080-375
Reversed condenser water
connections
107A Condenser with reversed water inlet/outlet Easyinstallationonsiteswithspecic
requirements
080-375
J-Bus gateway 148B Two-directionalcommunicationboard
complying with JBus protocol
Connectstheunitbycommunicationbustoa
buildingmanagementsystem
080-375
BacNet gateway 148C Two-directionalcommunicationboard
complying with BacNet protocol
Easyconnectionbycommunicationbustoa
buildingmanagementsystem
080-375
Longateway 148D Two-directionalcommunicationboard
complyingwithLonTalkprotocol
Connectstheunitbycommunicationbustoa
buildingmanagementsystem
080-375
High condensing temperature 150 Increasedcondenserleavingwater
temperatureupto63°C.Controloftheleaving
watertemperature.
Allows applications with high condensing
temperature (for heat reclaim or dry cooler
applications)
080-375
High condensing temperature in
non-reversibleapplications
150A Operation in heat pump mode only with
condenser leaving water temperature up to
63°C.
Allows applications with high condensing
temperature (for heat reclaim or dry cooler
applications)
080-375
Controlforlowcond.temperature
systems
152 Output signal (0-10 V) to control the condenser
water inlet valve
Simple installation: for applications with cold water
atcondenserinlet(ex.ground-source,
groundwater-source,supercialwater-source
applications) the signal permits to control a 2 or
3-way valve to maintain condenser water
temperature (and so condensing pressure) at
acceptablevalues
080-375
RS 485 communication interface
with open protocol
155 AdditionalRS485communicationboard Communication via CCN protocol 080-375
Dualreliefvalvesinstalledw/
3-way valve
194 Three-way valve upstream of the relief valves
on the evaporator and the oil separator
Valve replacement and inspection facilitated
withoutrefrigerantloss.ComformstoEuropean
standardEN378/BGVD4
080-190
Compliance with Swiss
regulations
197 Additional tests on the water heat exchangers:
supply(additionalofPEDdocuments)
supplementarycerticatesandtest
certications
Conformance with Swiss regulations 080-375
Compliance with Russian
regulations
199 EACcertication Conformance with Russian regulations 080-375
Welded water exchanger
connection kit
266 "Victaulic piping connections with welded
joints
"
Easy installation 080-375
Welded condenser water
connection kit
267 Victaulicpipingconnectionswithweldedjoints Easy installation 080-375
Flanged evaporator water
connection kit
268 Victaulicpipingconnectionswithangedjoints Easy installation 080-375
Flanged condenser water
connection kit
269 Victaulicpipingconnectionswithangedjoints Easy installation 080-375
230V electrical plug 284
230V AC power supply source provided with
plug socket and transformer (180 VA, 0,8 Amps)
Permits connection of a laptop or an electrical
device during unit commissioning or servicing
080-375
