Carrier 30HXC User Manual

17


   100 110 120 130 140 155 175  200 230 260  310 345 375
 kg 2274 2279 2302 2343 2615 2617 2702 2712 3083 3179 3873 4602 4656 4776 5477 5553 5721
 kg HFC-134a
Circuit A 33 33 32 31 49 51 48 54 54 70 92 115 117 132 109 96 119
Circuit B 34 34 30 35 52 47 48 57 50 70 68 63 75 80 106 109 137
 PolyolesteroilCARRIERSPEC.PP47-32
Circuit A l 15 15 15 15 15 15 15 15 15 15 30 30 30 30 30 30 30
Circuit B l 15 15 15 15 15 15 15 15 15 15 15 15 15 15 30 30 30
 Semi-hermetic, twin-screw POWER3
Size - Circuit A 39 46 46 56 56 66 80 80 80 80+ 66/56 80/56 80/80 80+/80+ 80/66 80/80 80+/80+
Size - Circuit B 39 39 46 46 56 56 56 66 80 80+ 66 80 80 80+ 80/66 80/80 80+/80+
 PRO-DIALOGPluscontrol
No.ofcontrolsteps 6 6 6 6 6 6 6 6 6 6 8 8 8 8 10 10 10
Minimum step capacity % 19 19 21 19 21 19 17 19 21 21 14 14 14 14 10 10 10
 Shellandtubewithinternallynnedcoppertubes
Net water volume l 50 50 58 69 65 65 75 75 88 88 126 155 170 170 191 208 208
Water connections Victaulic connections
Inlet/outlet in 4 4 4 5 5 5 5 5 5 5 6 6 6 6 8 8 8
Drainandvent(NPT) in 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8
Max.water-sideoperatingpressure kPa 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
 Shellandtubewithinternallynnedcoppertubes
Net water volume l 48 48 48 48 78 78 90 90 108 108 141 190 190 190 255 255 255
Water connections Victaulic connections
Inlet/outlet in 5 5 5 5 5 5 5 5 6 6 6 8 8 8 8 8 8
Drainandvent(NPT) in 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8
Max.water-sideoperatingpressure kPa 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
* Theweightsshownareguidelinesonly.Fortheunitrefrigerantchargepleaserefertotheunitnameplate.
** Nominalsizepercompressor.Thecompressorsizeisthesameasitsnominalcoolingcapacityintonsofrefrigeration(1ton=3.517kW).

Carrier 30HXC Specifications
