22

   100 110 120 130 140 155 175  200 230 260  310 345 375

Nominalpowersupply(Un)* V-ph-Hz 380-3-60
Voltage range V 342-418
 The control circuit is supplied via the factory-installed transformer
 kW 107 119 131 146 162 180 196 214 231 277 279 312 347 415 429 462 553
Circuit A kW - - - - - - - - - - 180 196 231 277 214 231 277
Circuit B kW - - - - - - - - - - 99 116 116 138 214 231 277


A 203 225 246 275 304 337 367 400 431 517 522 582 646 776 800 862 1034
Circuit A A - - - - - - - - - - 337 367 431 517 400 431 517
Circuit B A - - - - - - - - - - 185 215 215 259 400 431 517


A 184 204 224 250 276 306 334 364 392 470 474 530 588 705 728 784 940
Circuit A A - - - - - - - - - - 306 334 392 470 364 392 470
Circuit B A - - - - - - - - - - 168 196 196 235 364 392 470


A 301 301 320 356 347 430 465 496 534 648 1225 1374 1443 1775 1580 1656 2013
Circuit A
A - - - - - - - - - - 1050 1161 1230 1537 1192 1230 1537
Circuit B
A - - - - - - - - - - 906 1017 1017 1299 1192 1230 1537


1,54 1,40 1,37 1,36 1,33 1,35 1,30 1,28 1,25 1,36 2,48 2,41 2,26 2,49 2,04 1,94 2,11
Max.startingcurrent/max.
current draw ratio, circuit A
- - - - - - - - - - 3,29 3,25 2,89 3,23 3,07 2,89 3,23
Max.startingcurrent/max.
current draw ratio, circuit B
- - - - - - - - - 5,18 4,77 4,77 5,46 3,07 2,89 3,23


A std std std std std std std std std std 799 932 1001 1196 1138 1214 1434
Circuit A A - - - - - - - - - - 624 719 788 958 750 788 958
Circuit B A - - - - - - - - - - 400 435 435 600 750 788 958


std std std std std std std std std std 1,62 1,64 1,57 1,68 1,47 1,42 1,51
Circuit A - -
- - - - - - - - 1,96 2,01 1,85 2,01 1,93 1,85 2,01
Circuit B - - - - - - - - - - 2,29 2,04 2,04 2,52 1,93 1,85 2,01


kA 25 25 25 25 25 25 25 25 25 25 N/A N/A N/A N/A N/A N/A N/A
Circuit A kA - - - - - - - - - - 25 25 25 25 25 25 25
Circuit B kA - - - - - - - - - - 15 15 15 15 25 25 25



kW 8 8 8 11 11 11 15 15 15 15 15 18 18 30 30 30 30
* Power input, compressor, at unit operating limits (evaporator water entering/leaving temperature = 15°C/10°C, condensing temperature = 68°C) and a nominal voltage
of460V(datagivenontheunitnameplate).
** Maximumunitoperatingcurrentatmaximumunitpowerinput.
Maximum instantaneous starting current (maximum operating current of the smallest compressor(s) + locked rotor current or reduced starting current of the largest
compressor)
Currentandpowerinputsnotincludedinthevaluesabove
N/ANotapplicable

   MHA    
 39 43 67 330 104 NA NA
 46 49 80 330 104 NA NA
 56 61 100 405 128 175 210
 66 73 120 485 153 205 250
 80 88 143 580 183 245 300
 80+ 97 162 685 216 285 345

06NA - Compressor for air-cooled units
N - Non-economized compressor
E - Economized compressor
Inom. -AveragecurrentdrawofthecompressoratARIconditions
MHA - Must hold amperes (maximum operating current) at 342 V (A)
LRA -Lockedrotorcurrentwithacross-the-linestart
LRA(Y) -Lockedrotorcurrentatreducedcurrent(star/deltastart-upmode)
LRA(S)1cp. -Start-upwithreducedcurrentwithelectronicstarter(start-upduration3secondsmax.)foronecompressorpercircuit
LRA(S)2cp. -Start-upwithreducedcurrentwithelectronicstarter(start-upduration3secondsmax.)fortwocompressorspercircuit
