Carrier 30HXC User Manual

13


   100 110 120 130 140 155 175  200 230 260  310 345 375

Sound power level
(1)
dB(A) 94 94 94 94 94 97 98 100 101 101 99 101 102 102 103 104 104
Sound pressure level at 1 m
(2)
dB(A) 77 77 77 77 76 79 80 82 83 83 80 82 83 83 84 85 85

kg 2274 2279 2302 2343 2615 2617 2702 2712 3083 3179 3873 4602 4656 4776 5477 5553 5721
 Semi-hermetic, twin-screw Thecompressorsizeisidentiedbyitsnominalcoolingcapacityintonsofrefrigeration
(1ton=3.517kW)
Circuit A 39 46 46 56 56 66 80 80 80 80+ 66/56 80/56 80/80 80+/80+ 80/66 80/80 80+/80+
Circuit B 39 39 46 46 56 56 56 66 80 80+ 66 80 80 80+ 80/66 80/80 80+/80+

(3)
R-134a
Circuit A
kg 33 33 32 31 49 51 48 51 54 56 92 115 117 117 109 104 119
teqCO
2
47 47 46 44 70 73 69 73 77 80 132 164 167 167 156 149 170
Circuit B
kg 34 34 30 35 52 47 48 50 50 59 54 63 75 75 106 102 137
teqCO
2
49 49 43 50 74 67 69 72 72 84 77 90 107 107 152 146 196

(4)
PolyolesteroilCARRIERSPEC.PP47-32
Circuit A/B
l 17/17 17/17 17/17 17/17 17/17 17/17 17/17 17/17 17/17 17/17 30/17 30/17 30/17 30/17 34/34 34/34 34/34
 PRO-DIALOGPluscontrol
No.ofcontrolsteps 6 6 6 6 6 6 6 6 6 6 8 8 8 8 10 10 10
Minimum step capacity
% 19 19 21 19 21 19 17 19 21 21 14 14 14 14 10 10 10
 Shellandtubewithinternallynnedcoppertubes
Net water volume
l 50 50 58 69 65 65 75 75 88 88 126 155 170 170 191 208 208
Water connections Victaulic connections
Inlet/outlet
in 4 4 4 5 5 5 5 5 5 5 6 6 6 6 8 8 8
Drainandvent(NPT)
in 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8
Max.water-sideoperatingpressure
kPa 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
 Shellandtubewithinternallynnedcoppertubes
Net water volume
l 48 48 48 48 78 78 90 90 108 108 141 190 190 190 255 255 255
Water connections Victaulic connections
Inlet/outlet
in 5 5 5 5 5 5 5 5 6 6 6 8 8 8 8 8 8
Drainandvent(NPT)
in 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8
Max.water-sideoperatingpressure kPa 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
(1)
 IndBref=10-12W,(A)weighting.DeclareddualnumbernoiseemissionvaluesinaccordancewithISO4871(withanassociateduncertaintyof+/-3dB(A)).Measuredin
accordancewithISO9614-1andcertiedbyEurovent.
(2)
IndBref20µPa,(A)weighting.DeclareddualnumbernoiseemissionvaluesinaccordancewithISO4871(withanassociateduncertaintyof+/-3dB(A)).For
information,calculatedfromthesoundpowerlevelLw(A).
(3)
Valuesshownareguidelinesonly.Pleaserefertotheunitnameplate.
(4)
Foroptions150and150Atheunitsaresuppliedwithanadditionalchargeof3litrespercompressor.
