Carrier 30HXC User Manual

21

   100 110 120 130 140 155 175  200 230 260  310 345 375

Nominalpowersupply(Un)* V-ph-Hz 380-3-60
Voltage range V 342-418
 The control circuit is supplied via the factory-installed transformer
 kW 56 63 69 78 82 91 103 111 123 129 142 166 189 198 223 249 261
 A 114 123 132 146 161 178 198 215 235 257 276 315 352 386 430 469 515
 % 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
 kW 87 96 105 118 130 144 159 172 187 212 223 253 281 318 344 374 424
Circuit A** kW - - - - - - - - - - 144 159 187 212 172 187 212
Circuit B** kW - - - - - - - - - - 79 94 94 106 172 187 212


A 162 178 194 218 242 266 294 319 246 392 412 467 519 588 637 692 784
Circuit A*** A - - - - - - - - - - 266 294 346 392 319 346 392
Circuit B*** A - - - - - - - - - - 145 173 173 196 319 346 392


A 148 162 177 198 220 242 267 290 315 356 374 424 472 534 580 630 712
Circuit A*** A - - - - - - - - - - 242 267 315 356 290 315 356
Circuit B*** A - - - - - - - - - - 132 157 157 178 290 315 356



A 189 189 203 229 225 279 313 335 360 417 778 908 955 1113 1062 1112 1291
Circuit A*** A - - - - - - - - - - 646 751 798 935 773 798 935
Circuit B*** A - - - - - - - - - - 536 641 641 757 773 798 935


1,28 1,17 1,15 1,16 1,14 1,15 1,17 1,16 1,15 1,17 2,08 2,14 2,03 2,08 1,84 1,77 1,81
Max.startingcurrent/max.current
draw ratio, circuit A - - - - - - - - - - 2.67 2.81 2.54 2.63 2.67 2.54 2.63
Max.startingcurrent/max.current
draw ratio, circuit B - - - - - - - - - 4,06 4,08 4,08 4,25 2,67 2,54 2,63



A std std std std std std std std std std 592 667 714 836 821 871 1014
Circuit A A - - - -
- - - - - - 460 510 557 658 532 557 658
Circuit B A - - - - - - - - - - 260 330 330 400 532 557 658


std std std std std std std std std std 1,58 1,57 1,52 1,57 1,42 1,39 1,42
Circuit A - - - - - - - - - - 1,90 1,91 1,77 1,85 1,84 1,77 1,85
Circuit B - - - - - - - - - - 1,97 2,10 2,10 2,25 1,84 1,77 1,85


kA 25 25 25 25 25 25 25 25 25 25 N/A N/A N/A N/A N/A N/A N/A
Circuit A kA - - - - - - - - - - 25 25 25 25 25 25 25
Circuit B kA - - - - - - - - - - 15 15 15 15 25 25 25



‡
kW 8 8 8 11 11 11 15 15 15 15 15 18 18 30 30 30 30
* BasedonstandardisedARIconditions:Evaporatorentering/leavingwatertemperature12.2°Cand6.7°C.Condenserentering/leavingwatertemperature29.6°C/35°C.
** Power input, compressor, at unit operating limits (evaporator water entering/leaving temperature = 15°C/10°C, condenser entering/leaving water temperature =
45°C/50°C)andanominalvoltageof460V(datagivenontheunitnameplate).
*** Maximumunitoperatingcurrentatmaximumunitpowerinput.

Maximum instantaneous starting current (maximum operating current of the smallest compressor(s) + locked rotor current or reduced starting current of the largest
compressor)
‡
 Currentandpowerinputsnotincludedinthevaluesabove.
 N/ANotapplicable
