11

 A    E F
200 3903 1015 1980 3600 1000 489
 3924 1015 2060 3600 1000 489
310-345-375 4533 1015 2112 4200 1000 503
NOTE: Refer to the certied dimensional drawings supplied
with the unit, when designing an installation.
4
2
E
500
B
3
A
C
D
700
3
4
500
3
F
1

 Alldimensionsareinmm.
Evaporator
Condenser
Clearances required for operation and maintenance
 Clearancesrequiredforheatexchangertuberemoval.ClearancesD
andEcanbeeitherontheleftorontherighthandside.
Water inlet
Water outlet
Power supply
a
b
c
d
