19

   100 110 120 130 140 155 175  200 230 260  310 345 375

Nominalpowersupply(Un)* V-ph-Hz 460-3-60
Voltage range V 414-506
 The control circuit is supplied via the factory-installed transformer
 kW 107 119 131 146 162 180 196 214 231 277 279 312 347 415 429 462 553
Circuit A kW - - - - - - - - - - 180 196 231 277 214 231 277
Circuit B kW - - - - - - - - - - 99 116 116 138 214 231 277


A 167 185 204 227 251 278 303 331 356 427 431 481 534 641 662 712 854
Circuit A A - - - - - - - - - - 278 303 356 427 331 356 427
Circuit B A - - - - - - - - - - 153 178 178 214 331 356 427


A 152 169 185 207 228 253 276 301 324 388 392 438 486 582 602 648 776
Circuit A A - - - - - - - - - - 253 276 324 388 301 324 388
Circuit B A - - - - - - - - - - 139 162 162 194 301 324 388


A 234 264 280 313 302 378 410 436 467 568 1084 1215 1272 1569 1386 1448 1766
Circuit A
A - - - - - - - - - - 939 1039 1096 1372 1065 1096 1372
Circuit B
A - - - - - - - - - - 820 920 920 1175 1065 1096 1372


1,44 1,48 1,44 1,45 1,40 1,43 1,39 1,36 1,33 1,44 2,65 2,58 2,41 2,65 2,16 2,06 2,24
Max.startingcurrent/max.
current draw ratio, circuit A
- - - - - - - - - - 3,56 3,52 3,11 3,48 3,32 3,11 3,48
Max.startingcurrent/max.
current draw ratio, circuit B
- - - - - - - - - 5,66 5,23 5,23 5,96 3,32 3,11 3,48


A std std std std std std std std std std 744 870 927 1054 1041 1103 1251
Circuit A A - - - - - - - - - - 599 694 751 857 720 751 857
Circuit B A - - - - - - - - - - 400 435 435 550 720 751 857


std std std std std std std std std std 1,82 1,85 1,76 1,78 1,62 1,57 1,59
Circuit A - -
- - - - - - - - 2,27 2,35 2,13 2,18 2,24 2,13 2,18
Circuit B - - - - - - - - - - 2,76 2,47 2,47 2,79 2,24 2,13 2,18


kA 25 25 25 25 25 25 25 25 25 25 N/A N/A N/A N/A N/A N/A N/A
Circuit A kA - - - - - - - - -. - 25 25 25 25 25 25 25
Circuit B kA - - - - - - - - - - 15 15 15 15 25 25 25



kW 8 8 8 11 11 11 15 15 15 15 15 18 18 30 30 30 30
* Power input, compressor, at unit operating limits (evaporator water entering/leaving temperature = 15°C/10°C, condensing temperature = 68°C) and a nominal voltage
of460V(datagivenontheunitnameplate).
** Maximumunitoperatingcurrentatmaximumunitpowerinput.
Maximum instantaneous starting current (maximum operating current of the smallest compressor(s) + locked rotor current or reduced starting current of the largest
compressor)
Currentandpowerinputsnotincludedinthevaluesabove
N/ANotapplicable
