18

   100 110 120 130 140 155 175  200 230 260  310 345 375

Nominalpowersupply(Un)* V-ph-Hz 460-3-60
Voltage range V 414-506
 The control circuit is supplied via the factory-installed transformer
 kW 56 63 69 78 82 91 103 111 123 129 142 166 189 198 223 249 261
 A 94 101 109 121 133 147 164 178 194 213 228 260 291 319 355 388 425
 % 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
 kW 87 96 105 118 130 144 159 172 187 212 223 253 281 318 344 374 424
Circuit A** kW - - - - - - - - - - 144 159 187 212 172 187 212
Circuit B** kW - - - - - - - - - - 79 94 94 106 172 187 212


A 134 147 161 180 200 220 243 263 286 324 340 386 429 486 526 572 648
Circuit A*** A - - - - - - - - - - 220 243 286 324 263 286 324
Circuit B*** A - - - - - - - - - - 120 143 143 162 263 286 324


A 122 134 146 164 182 200 221 239 260 294 309 351 390 441 478 520 588
Circuit A*** A - - - - - - - - - - 200 221 260 294 239 260 294
Circuit B*** A - - - - - - - - - - 109 130 130 147 239 260 294



A 165 165 177 201 195 244 274 292 313 363 685 801 840 979 928 970 1126
Circuit A*** A - - - - - - - - - - 576 671 710 832 689 710 832
Circuit B*** A - - - - - - - - - - 485 580 580 685 689 710 832


1,35 1,23 1,21 1,23 1,19 1,22 1,24 1,22 1,20 1,23 2,22 2,28 2,15 2,22 1,94 1,87 1,91
Max.startingcurrent/max.current
draw ratio, circuit A - - - - - - - - - - 2,88 3,04 2,73 2,83 2,88 2,73 2,83
Max.startingcurrent/max.current
draw ratio, circuit B - - - - - - - - - 4,45 4,46 4,46 4,66 2,88 2,73 2,83



A std std std std std std std std std std 550 621 660 714 748 790 861
Circuit A A - - - -
- - - - - - 441 491 530 567 509 530 567
Circuit B A - - - - - - - - - - 260 330 330 370 509 530 567


std std std std std std std std std std 1,78 1,77 1,69 1,62 1,56 1,52 1,46
Circuit A - - - - - - - - - - 2,21 2,22 2,04 1,93 2,13 2,04 1,93
Circuit B - - - - - - - - - - 2,39 2,54 2,54 2,52 2,13 2,04 1,93


kA 25 25 25 25 25 25 25 25 25 25 N/A N/A N/A N/A N/A N/A N/A
Circuit A kA - - - - - - - - - - 25 25 25 25 25 25 25
Circuit B kA - - - - - - - - - - 15 15 15 15 25 25 25



‡
kW 8 8 8 11 11 11 15 15 15 15 15 18 18 30 30 30 30
* BasedonstandardisedARIconditions:Evaporatorentering/leavingwatertemperature12.2°Cand6.7°C.Condenserentering/leavingwatertemperature29.6°C/35°C.
** Power input, compressor, at unit operating limits (evaporator water entering/leaving temperature = 15°C/10°C, condenser entering/leaving water temperature =
45°C/50°C)andanominalvoltageof460V(datagivenontheunitnameplate).
*** Maximumunitoperatingcurrentatmaximumunitpowerinput.

Maximum instantaneous starting current (maximum operating current of the smallest compressor(s) + locked rotor current or reduced starting current of the largest
compressor)
‡
 Currentandpowerinputsnotincludedinthevaluesabove.
 N/ANotapplicable
