Carrier i-Vu XT Router User Manual

i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022
Installation and Start-up Guide 15 All rights reserved
To set the Port S1 address and baud rate
The address should be in one of the following ranges based on the port's use.
• For ARCNET, the range is 1 to 254.
• For MS/TP, the range is 0 to 127.
On the Connections > Port S1 tab, type the address in the MAC Address field.
NOTE ARCNET is not supported on Port S2.
For MS/TP, set up the port's baud rate
1 On the Connections > Port S1 tab, select the Baud Rate. The default is 76,800 bps.
2 Click .
To set the Port S2 address and baud rate
1 On the Connections > Port S2 tab, type the address in the MAC Address field. The address must be in the
range of 0 to 127.
2 Select the MSTP Baud Rate. The default is 76,800 bps.
NOTE Enter the same baud rate for all devices on the MS/TP network.
3 Click .
