i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022
Installation and Start-up Guide 27 All rights reserved
Port S1 and Port S2
Port S1
Port S1 BACnet/MSTP
Enable for a BACnet/MSTP network.
Auto Generate Network
Number
If checked, network number is autogenerated, which then automatically sets to
((IP network number + rotary switch address) x 10) + 0.
Uncheck to use Custom Static Address Mode.
Network Number
The network number is 0 by default. Filled in automatically if Autogenerate
Network Number is checked.
NOTE When downloaded from the i-Vu® application, these numbers match those
set using SiteBuilder.
MAC Address
You set the address for Port S1, which must be unique for the system.
End of Network
Indicates status of the router's End of Net? switch.
Max Master
To increase MS/TP performance, enter the highest address used on the MS/TP
network for a master controller. This number must be less than or equal to 127.
Max Info Frames
This is the maximum number of information messages a controller may transmit
before it must pass the token to the next controller. Valid values are 1 to 255.
TIP Set Max Info Frames to a number in the range 20 to 100 so that the
router does not become a bottleneck for traffic being routed from a high-speed
network to the slower MS/TP network.
APDU Length
The maximum length of a message or message segment that can be accepted by
the BACnet device.
Baud Rate
Set this to a baud rate that all other devices on the MS/TP network are set to.
Select 9600, 19200, 38400, 57600, 76800, or 115200.
Port S1 BACnet/ARCNET
Enable for a BACnet/ARCNET network.
Auto Generate Network
Number
If checked, network number is autogenerated, which then automatically sets to
((IP network number + rotary switch address) x 10) + 0.
Uncheck to use Custom Static Address Mode.
Network Number
The network number is 0 by default. Filled in automatically if Autogenerate
Network Number is checked.
NOTE When downloaded from the i-Vu® application, these numbers match those
set using SiteBuilder.
MAC Address
You set the address for Port S1, which must be unique for the system.
End of Network
Indicates status of the router's End of Net? switch.
