Carrier i-Vu XT Router User Manual

i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022
Installation and Start-up Guide 16 All rights reserved
The i-Vu® XT Router communicates on the following ports.
Port
Protocol
Port type(s)
Speed(s)
Gig-E
BACnet/IPv4
BACnet/IPv6
and/or BACnet/Ethernet
Ethernet
10, 100, or 1000 Mbps (1 Gbps)
Port S1
1
BACnet/ARCNET
RS485
156 kbps
Port S1
1
or
Port S2
BACnet/MSTP
RS485
9.6 to 115.2 Kbps
2
Service Port
3
HTTP/IP
Ethernet
10 Mbps
100 Mbps
USB Port
USB2.0
USB
1
Set the Port S1 Configuration rotary switch to:
0 if the port is not used
1 for MS/TP
2 for ARCNET
2
Default for MS/TP is 76.8 kbps.
3
See Connecting to the router through the Service Port (page 8).
Wiring specifications
For...
Use...
Maximum Length
Ethernet
Cat5e or higher Ethernet cable
328 feet (100 meters)
ARCNET
22 AWG, low-capacitance, twisted, stranded,
shielded copper wire *
2000 feet (610 meters)
MS/TP
22 AWG, low-capacitance, twisted, stranded,
shielded copper wire *
2000 feet (610 meters)
*
See the Open Controller Network Wiring Guide.
WARNING Do not apply line voltage (mains voltage) to the router's ports and terminals.
Wiring for communications
