i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022
Installation and Start-up Guide 2 All rights reserved
The i-Vu® XT Router has 4 physical BACnet communication ports:
Port
Port type
For routing this type
of communication...
At...
Gig-E
10/100/1000 Mbps Ethernet
BACnet/IP
BACnet/Ethernet
10, 100, or 1000 Mbps (1
Gbps)
S1
High-speed EIA-485 port
BACnet/ARCNET
BACnet/MSTP
156 kbps
9.6 to 115.2 kbps
S2
Electrically isolated EIA-485 port
BACnet/MSTP
9.6 to 115.2 Kbps
Service
Port
10/100 Mbps Ethernet
HTTP/IP
BACnet/IP Service Port
10 or 100 Mbps
i-Vu® XT Router also has a USB port for recovery.
Specifications
Driver
drv_gen5_< version >
NOTE For the fwex driver instructions, see the (part# i-Vu® XT Router) (drv_fwex)
Installation and Start-up Guide.
Power
24 Vac ±10%, 50–60 Hz, 50 VA
26 Vdc ±10%, 15 W
Gig-E port
10/100/1000 BaseT Ethernet port for BACnet/IP and/or BACnet/Ethernet
communication on the Ethernet at 10, 100, or 1000 Mbps, full duplex
Port S1
For communication with either of the following:
• A BACnet ARCNET network at 156 kbps
• A BACnet MS/TP network at 9600 to 115200 bps
This port's End of Net? switch can be set to Yes to terminate the network segment.
Port S2
For communication with a BACnet MS/TP network at 9600 to 115200 bps. This
port's End of Net? switch can be set to Yes to terminate the network segment.
Service Port
Ethernet port at 10 or 100 Mbps for system start-up and troubleshooting
USB port
USB 2.0 host port for device recovery
Microprocessor
32-bit ARM Cortex-A8, 600MHz, processor with multi-level cache memory
Memory
16 GBs eMMC Flash memory (120 MB available for use) and 256 MB DDR3
DRAM.
User data is archived to non-volatile Flash memory when parameters are changed,
every 90 seconds, and when the firmware is deliberately restarted.
Real-time clock
Real-time clock keeps track of time in the event of a power failure for up to 3 days.
