109
Bridge Satellite Cradle
3
Using the Bridge Satellite Cradle
The optional AC adaptor (AD-S42120AE) is used to supply power to the Bridge
Satellite Cradle. Note that you cannot use the AC adaptor (AD-S15050AE) that
comes with the Rugged PDA.
1. Turn off the Bridge Satellite Cradle and the PC you will be connecting to
it.
2. Connect the specified AC adaptor to the Bridge Satellite Cradle connec-
tor.
On the back of the Bridge Satellite Cradle, remove the cover cap from the
USB port or the RS-232C connector. Take care not to lose the cap.
Connect an optional USB cable (DT-380USB) to the USB port, and an
optional RS-232 cable (DT-887AX or DT-882RSC or DT-883RSC) to the
RS-232C connector.
3. Turn on Bridge Satellite Cradle power.
The POWER lamp on the front of the cradle will light red.
4. Mount the Rugged PDA on the Bridge Satellite Cradle.
The POWER lamp on the front of the cradle will change to green.
IT-10_3/101-122.p65 06.6.15, 6:49 PM109
