117
Communication Card Cover
3
Communication Card Cover (HA-C92TCV)
Loading a communication card into the card slot of the Rugged PDA makes it possible to
perform mobile Internet browsing in a train station, hotel, etc.
A communication card cover is provided to cover the raised card antenna to avoid
unexpected accidents, to protect the antenna from impact, and to keep out dust and rain
while using the card.
1. Use a coin or similar object
to remove the two screws
that secure the card cover,
and remove it from the
Rugged PDA. Store the card
cover in a safe place and
make sure you do not lose it.
2. Taking care that the card is oriented
correctly, carefully slide it into the
card slot as far as it will go.
3. Being careful with the raised communication card antennal, install the
communication card cover and secure it in place with the two different
kinds of screw, each with two screws.
Tighten the two screws you
removed in step 1 from the
bottom.
Tighten the two screws
accompanied with the card
cover from the left and right
sides.
Remove these
two screws.
IT_10/101-122-E.p65 06.7.5, 6:28 PM117
