E-32
Part 15 Reference
This section contains information about the Label Printer that you can use as
reference when you need it.
Cleaning the Printer Head and Roller
A dirty printer head and roller can result in poor printing quality. If you have
problems with print quality, use the following procedure to clean the printer head
and roller.
To clean the printer head and roller
1. Make sure the Label Printer is turned off.
2. Open the cassette cover.
• If a tape cartridge is loaded in the printer, remove it.
3. Use a cotton swab dipped in alcohol to clean the printer head and roller as
shown in the illustration.
• Never touch the print head or other metal objects near the head. These items
become very hot, and touching them creates the risk of burn injury.
4. Replace the tape cartridge and close the cover.
Roller
Printer head
Cleaning the Printer Exterior
Wipe the exterior of the printer with a cloth moistened with plain water.
Wring all excess liquid from the cloth before wiping the printer.
Never use benzene, alcohol, thinner, or other volatile agents to clean the
printer exterior. Doing so can damage the case.
FUNC key has been
pressed.
Press ESC to clear FUNC key
operation.
E-12
Load a fresh set of AA-size alkaline
batteries (supplied by you).
Adjust display contrast.
Remove batteries and reload them
correctly.
Make sure the AC adaptor is
connected correctly.
Nothing appears on the display.
Possible Causes Action Page
E-8
E-31
E-8
E-9
Battery power is low or
the wrong type of
batteries are loaded in
the printer.
Improper display contrast
setting
Batteries loaded
incorrectly
AC adaptor (option) is
not connected correctly.
Cannot input text.
Possible Causes Action Page
Troubleshooting
••
••
•
Power Supply
••
••
•
Text Input
To Next Page
