Supported timing for HDMI input
• PC timings
• Video timings
Supported timing for Component-YPbPr input
Resolution Mode
Vertical Frequency
(Hz)
Horizontal
Frequency (kHz)
Pixel Frequency
(MHz)
640 x 480 VGA_60 59.940 31.469 25.175
800 x 600 SVGA_60 60.317 37.879 40.000
1024 x 768 XGA_60 60.004 48.363 65.000
1280 x 720 1280 x 720_60 60 45.000 74.250
1280 x 768 1280 x 768_60 59.870 47.776 79.5
1280 x 800 WXGA_60 59.810 49.702 83.500
1280 x 1024 SXGA_60 60.020 63.981 108.000
1280 x 960 1280 x 960_60 60.000 60.000 108
1400 x 1050 SXGA+_60 59.978 65.317 121.750
1920 x 1200@60Hz
1920 x 1200_60 (Reduce
Blanking)
59.95 74.038 154
1920 x 1080 (VESA) 1920 x 1080_60 59.963 67.158 173
The timings showing above may not be supported due to EDID file and VGA graphic card limitations. It is
possible that some timings cannot be chosen.
Timing Resolution
Vertical
Frequency (Hz)
Horizontal Frequency
(kHz)
Pixel Frequency
(MHz)
480p 720 x 480 59.94 31.47 27
576p 720 x 576 50 31.25 27
720/50p 1280 x 720 50 37.5 74.25
720/60p 1280 x 720 60 45.00 74.25
1080/50i 1920 x 1080 50 28.13 74.25
1080/60i 1920 x 1080 60 33.75 74.25
1080/50P 1920 x 1080 50 56.25 148.5
1080/60P 1920 x 1080 60 67.5 148.5
2160/24P 3840 x 2160 24 54 297
2160/25P 3840 x 2160 25 56.25 297
2160/30P 3840 x 2160 30 67.5 297
2160/50P* 3840 x 2160 50 112.5 594
2160/60P* 3840 x 2160 60 135 594
*Supported only when an HDMI 1 (HDCP2.2) port is in use.
Timing Resolution
Vertical Frequency
(Hz)
Horizontal Frequency
(kHz)
Pixel Frequency
(MHz)
480i 720 x 480 59.94 15.73 13.5
480p 720 x 480 59.94 31.47 27
576i 720 x 576 50 15.63 13.5
576p 720 x 576 50 31.25 27
720/50p 1280 x 720 50 37.5 74.25
720/60p 1280 x 720 60 45.00 74.25
1080/50i 1920 x 1080 50 28.13 74.25
1080/60i 1920 x 1080 60 33.75 74.25
1080/50P 1920 x 1080 50 56.25 148.5
1080/60P 1920 x 1080 60 67.5 148.5

Casio XJ-L8300HN Specifications

General

Brand	Casio
Model	XJ-L8300HN
Category	Projector
Language	English
