Chromalox 2104 User Manual

Chromalox 2104 Technical Manual 33
Section 4
Controller Setup PAGEs
This section contains detailed information for the
following controller setup pages:
DISP: Display
CTRL: Control
INPT: Input
SCAL: Custom Scaling
OUT1: Output #1
OUT2: Output #2
Setup PAGEs specific to certain functions are located
in the section of this manual that addresses that
function specifically.
Section Page Topic Setup PAGE
5 Ramp/Soak RSPG
6 Alarms and Events OUT3, OUT4, OUT5
8 Remote Setpoint Input and CTRL, INPT, SCAL
Analog Output Option
9 Digital Communications DIG
Section
Contents
41
47
67
71
Throughout the following Setup PAGEs you will find
these symbols 40 . This indicates a section of this
User’s Manual where more specific information on a
parameter/application/feature can be found.
More
Info.
