Cisco 3200 Series Hardware Reference

1-18
Cisco 3200 Series Router Hardware Reference
OL-5816-10
Chapter 1 Cisco 3200 Rugged Enclosures
Cisco 3200 Rugged Enclosure LED Indications
This section describes the LED indications for the Cisco 3200 Rugged Enclosure I/O end caps.
Note The behavior of the WMIC LEDs is described in the “WMIC Console LEDs” section on page 1-19.
Cisco 3270 Rugged Enclosure I/O End Cap LED Indications
Table 1-2 lists the LEDs for the Cisco 3270 Rugged Enclosure I/O end caps and their indications.
Ta b l e 1-2 LEDs for the Cisco 3270 Rugged Enclosure End Cap
LED Indication
Cisco 3270 Rugged Router card Solid green: OK.
Blinking: Booting and self-testing.
Black: Not OK or the power is off.
Serial Status/Link (1 status/link
LED per serial port)
Solid green: Link OK.
Black: No link is detected.
Amber blink: Activity.
Fast Ethernet
(1 LED per port, except for the
fiber-optic port, which has no
LEDs)
Link LED
Solid green: Link OK.
Black: No link is detected.
Activity LED
Black: No activity and no connection.
Green blink: Activity.
Gigabit Ethernet
(2 LEDs per port)
Link LED
Solid green: Link OK.
Black: no link is detected.
Activity LED
Solid green: Link OK.
Black: No activity.
Green blink: Activity.
Console Solid green: Link OK.
Black: No activity.
Green blink: Activity.
WMIC Console (Installation or
Operation Mode)
For installation mode, see Table 1-4 on page 1-19.
For operation mode, see Table 1-5 on page 1-20.
