Cisco 3200 Series Hardware Reference

5-2
Cisco 3200 Series Router Hardware Reference
OL-5816-10
Chapter 5 Serial Mobile Interface Card
SMIC Component Systems
Figure 5-1 shows the 2-port SMIC header and bus locations.
Figure 5-1 2-port SMIC Header and Bus Locations
Figure 5-2 shows the 4-port SMIC header and bus locations.
Caution If you add non-Cisco cards that generate signals on the PCI bus, the router might shut down. Do not add
non-Cisco cards that generate signals on the PCI bus.
Figure 5-2 4-port SMIC Header and Bus Locations
1 PCI bus 2 60-pin multifunction header for Serial 0 and
Serial 1 signals
3 ISA bus 4 Rotary switch
95227
1 3
24
1 PCI bus 2 60-pin multifunction header for Serial 2 and
Serial 3 signals
3 60-pin multifunction header for Serial 0 and
Serial 1 signals
4 ISA bus
5 Rotary switch
74519
1 43
25
