5-5
Cisco 3200 Series Router Hardware R
eference
OL-5816-10
Chapter 5 Serial
Mobile Interface Card
SMIC Power Consumption
The SMIC draws po
wer from the PCI and the ISA connectors.
Ta
b
l
e
5-6
shows the estimated po
wer consumption. Note
that these are theoretical maximum w
attages.
Ta
b
l
e
5-6
SMIC Estima
ted P
ow
er Consumption
V
oltage
Current Draw
Power
Source
+5.0 V
1.0 A
5.0 W
ISA and PCI connectors
+3.3 V
0.5 A
1.7 W
PCI connectors
